ABS FTTA 8 Port Waterproof Terminal Box IP65

ABS FTTA 8 Port Waterproof Terminal Box IP65
ABS FTTA 8 Port Waterproof Terminal Box IP65 ABS FTTA 8 Port Waterproof Terminal Box IP65 ABS FTTA 8 Port Waterproof Terminal Box IP65

Large Image :  ABS FTTA 8 Port Waterproof Terminal Box IP65

Product Details:
Place of Origin: China
Brand Name: DOWELL
Model Number: DW-FTTA-8P
Payment & Shipping Terms:
Minimum Order Quantity: 500
Delivery Time: 7-15 days
Payment Terms: T/T,Western Union
Supply Ability: 500pcs per 7 days
Contact Now

ABS FTTA 8 Port Waterproof Terminal Box IP65

Description
Material: PC+ABS, Anti-aging, Wet-proof Protection Rating: IP65 – Waterproof And Dustproof
Operating Temperature: -40°C To +85°C Relative Humidity: ≤85% (at +30°C)
Insertion Loss: ≤ 0.15dB Return Loss (UPC/APC): ≥50 DB (UPC), ≥60 DB (APC)
Highlight:

8 Port Waterproof Terminal Box

,

ABS FTTA Terminal Box

,

IP65 Waterproof Terminal Box

ABS FTTA 8 Port Waterproof Terminal Box IP65 Waterproof

The Dowell Waterproof Terminal Box is a robust, environmentally sea 8 Port led fiber distribution solution designed for outdoor and harsh-environment fiber optic network deployments. This fiber optic distribution box provides secure splicing, storage, and distribution of up to 8 fiber cores, ensur reliable econnectivity for FTTH(Fiber-to-the-Home), 5G networks, and industrial applications. With an IP68-rated waterproof and dust-proof design, it protects critical fiber connections from moisture, temperature extremes, and mechanical stress. modular structure supports easy fiber management, mak it ideal for aerial, underground, or pole-mounted installations.
Specification:
Parameter Specification
Material PC+ABS, anti-aging, wet-proof
Protection Rating IP65 – Waterproof and Dustproof
Atmospheric Pressure 70KPa to 106KPa
Insertion Loss ≤ 0.15dB
Return Loss (UPC/APC) ≥50 dB (UPC), ≥60 dB (APC)
Max Capacity 36 fibers
Cable Entry Diameter 8-14mm
Branch Hole Diameter Maximum 16mm
Reinforced Adapter 8 pcs SC/UPC or SC/APC
Installation Pole mounting,Strand mounting,Wall-mounting
Feartures:
1.1 Total Enclosed Protection:
Ensures reliable, long-term fiber protection with a fully enclosed, waterproof, and dustproof structure.
1.2 High-Quality PC+ABS Construction:
Built for durability, resistant to environmental wear, and suitable for both indoor and outdoor fiber cable distribution box
1.3 Integrated Cable Management:
Manages feeder and drop cables, fiber splicing, and distribution while keeping cable paths separate for optimal organization and performance.
1.4 Micro PLC Splitter Installation:
Compatible with micro-type PLC splitters, allowing for flexible network configurations.
1.5 Flip-Up Distribution Panel:
Designed for easy access to the feeder cable and components, simplifying fiber optic termination box Versatile Mounting Options:  Offers both wall-mounted and pole-mounted installation for flexible deployment in various environments, supporting fiber distribution terminal.
Application:
2.1 FTTx Communication Networks:
A reliable termination and distribution solution for fiber-to-the-home (FTTH) networks, facilitating fiber access for residential and commercial users.
2.2 Commercial Buildings:
Suitable for high-density fiber installations, such as in fiber distribution boxes and optical fiber terminal boxes for structured cabling in business complexes.
2.3 Outdoor Fiber Networks:
With IP65-rated protection, it’s ideal for exposed environments, ensuring connectivity in outdoor setups, including fiber optic cable terminal box
