|STUB Block:||5/10/15/20/25Pair||Box:||5/10/15/20/25Pair Capacity|
|Protection:||With Gel Filled||Line Protection:||Module Without Protection|
|Cable:||Multi-pair Cable||Contact Material:||Phosphor Bronze|
25 Pair Subscriber Terminal Block STUB module block with LAN cable Without Protection
1. Available capacity: 5/10/15/20/25Pairs,up each 5Pairs as a unit
2. Each block equipped with Cable tail 2.8meters
3. Sealing Bottom:Epoxy Resin
4. With plug in module (subscribe connector unit )unprotection .
5.The module offers connection point between an exchange-side cable pair and a distribution pair
6.Plug-in module can be with protection type(over-voltage protection/Over voltage and over current protection) or without protection
This is used in terminating cables of secondary telephone networks to the cable pairs of subscriber lines. It consists of a body and cover which house a stubbed block.
5Pair STB modules as one unit STUB module block,the module can be with protection over-voltage or with protection over voltage and over current .
By the bottom of the box, there will enter the Multipair cable. The income thereof shall be protected to seal the set against the entry of water or moisture from the outside. The STUB block box also possess a mechanical retention that avoid spreading efforts will see subject the cable towards the inside of the box. These conditions shall not be affected by subjecting the cable to movements that normally can be exposed the whole during their use or installation.
Interior layout allows the comfortable handling of connections inside the box, facilitating their connection. For this purpose a enough distance between the side wall and the last row of modules. It will also facilitate the connection of Earth and the pair pilot conductor, which will have enough space.
The modules will be configured in groups (5pairs as one group) to form a block, which can be removed from the base of the box in case your replacement if necessary. Locking will take place by means of screws whose position will be based on a standardized template. The screws should be fixed using inserts in the base.
It is easily installed in the distribution box.The box is designed for wall mounting. The lid offers opening positions 90degree,135degree according to the amount of working space available, and with rubber grommet to limit water entry.Grommets are provided for dropwire access.The box locking mechanism is mounted through the cable stub and is effective on closing the box; to open the box again a special key or a screwdriver is required depending upon the lock type.The ground terminals of each pair are electrically connected to the cable shielding and to an external ground terminal.
The subscriber terminal box consists of a rectangular box base with a cover and a connection module secured to the base.The top and base are hinged together, and the top is easily removable to facilitate working in cramped conditions.The cable grommets for wire entry and exit may be adjusted to conductor size and are also removable.A metal screw is provided for grounding purposes.
Application for replacing Tyco VX-SB subscribe connector unit terminal blocks,Connecting 1 pair module without protection,module with surge protection (gas-discharge instrument with surge protection to 230V) and module with overvoltage and overcurrent (overvoltage to 230V, and by two resistors PTC, which protect from the overcurrent).
Used in interconnection point between secondary cable and service wire to subscribe houses.For mounting to walls,wood,metal or concrete poled.
4. Arial DP is equipped with pole mounting accessories as required.
Outdoor waterproof Distribution Box :The type of STB module is required as your application.
|YH-3010-1||1pair DP box for STB module (EMPTY) 95*45*50mm|
|YH-3010-1G||1pair DP box with STB module(YH-5027) 95*45*50mm|
|YH-3010-1R||1pair DP box with STB module(YH-5028) 95*45*50mm|
|YH-3010-1O||1pair DP box with STB module(YH-5029) 95*45*50mm|
|YH-3010-2||2pair DP box for STB module (EMPTY) 145*95*75mm|
|YH-3011||10pair DP box for STB module (EMPTY) 195*195*85mm|
|YH-3012||20pair DP box for STB module (EMPTY) 350*190*95mm|
|YH-3031||10pair DP box for STB module (EMPTY)|
|YH-3032||20pair DP box for STB module (EMPTY)|
