LSZH Duplex FC UPC to SC APC Fiber Optic Patch Cord for High-speed Internet Connection

LSZH Duplex FC UPC to SC APC Fiber Optic Patch Cord for High-speed Internet Connection
LSZH Duplex FC UPC to SC APC Fiber Optic Patch Cord for High-speed Internet Connection
LSZH Duplex FC UPC to SC APC Fiber Optic Patch Cord for High-speed Internet Connection LSZH Duplex FC UPC to SC APC Fiber Optic Patch Cord for High-speed Internet Connection LSZH Duplex FC UPC to SC APC Fiber Optic Patch Cord for High-speed Internet Connection LSZH Duplex FC UPC to SC APC Fiber Optic Patch Cord for High-speed Internet Connection

Large Image :  LSZH Duplex FC UPC to SC APC Fiber Optic Patch Cord for High-speed Internet Connection

Product Details:
Place of Origin: Zhejiang, China
Brand Name: DOWELL
Certification: CE
Model Number: DW-FUD-SAD
Payment & Shipping Terms:
Minimum Order Quantity: 1000 pieces
Delivery Time: 7-15 Days
Payment Terms: T/T, Western Union, Paypal
Supply Ability: 1000 PCS Per 7 Days
Contact Now

LSZH Duplex FC UPC to SC APC Fiber Optic Patch Cord for High-speed Internet Connection

Description
Fiber: Energy Fiber Type: Singlemode
Sheath Color: Light Blue / Other Outer Sheath: LSZH/PVC Patch Cord
Connector Type: LC/SC/FC/ST/MPO/MTP Calbe Type: Simplex,Duplex,4/6/8/12/24...fibers
Highlight:

LSZH Fiber Optic Patch Cord

,

Multi Fiber Optic Patch Cord

,

Multi fc to lc patch cord

LSZH Duplex FC UPC to SC APC SM Fiber Optic Patch Cord

Fiber Optic Patchcords are components to link equipments and components in fiber optic network. There are many types according to different types of fiber optic connector including FC SV SC LC ST E2000N MTRJN MPO etc. with single mode(9/125um) and multimode (50/125 or 62.5/125). Cable jacket material can be PVC, LSZH; OFNR, OFNP etc. There are simplex, duplex, multi fibers, Ribbon fan out and bundle fiber.

Specification:

Parameter Unit Mode PC UPC APC
Type
Insertion Loss dB SM <0.3 <0.3 <0.3
MM <0.3 <0.3
Return Loss dB SM >50 >50 >60
MM >35 >35
Repeatability dB Additional loss<0.1db, return loss< 5 dB
Interchangeability dB Additional loss<0.1db, return loss< 5 dB
Connection Times times >1000
Operating Temperature °C -40 C- +75 C
Storage Temperature °C -40 C- +85 C

Package:

1. Plastic bag

LSZH Duplex FC UPC to SC APC Fiber Optic Patch Cord for High-speed Internet Connection 0

2. Inner Box

LSZH Duplex FC UPC to SC APC Fiber Optic Patch Cord for High-speed Internet Connection 1

LSZH Duplex FC UPC to SC APC Fiber Optic Patch Cord for High-speed Internet Connection 2

3. Outer Box

LSZH Duplex FC UPC to SC APC Fiber Optic Patch Cord for High-speed Internet Connection 3

Application:

1. Telecommunication Network
2. Fiber Broad Band Network
3. CATV system
4. LAN and WAN system
5. FTTP

LSZH Duplex FC UPC to SC APC Fiber Optic Patch Cord for High-speed Internet Connection 4
