Multimode Duplex 0.75M Lc/Pc To Lc/Pc Om3 Mm Fiber Optic Cable Patch Cord -40 85

Product Details

Place of Origin: Zhejiang, China

Brand Name: DOWELL

Model Number: DW-LD-LD-M3

Payment & Shipping Terms

Minimum Order Quantity: 500 pieces

Price: $0.80 - $2.80/pieces

Packaging Details: Normal Package

Supply Ability: 30000 Piece/Pieces per Week

Get Best Price
Highlight:
Type:
Fiber Optic Patch Cord
Use:
FTTP,CATV
Repeatability:
Additional Loss< 0.1, Return Loss< 5
Interchangeability:
Additional Loss< 0.1, Return Loss< 5
Connection Times:
>1000
Operating Temperature:
-40 ~ +75
Storage Temperature:
-40 ~ +85
Warranty:
1 Year
No. Of Fiber:
4.
Port:
Ningbo
Type:
Fiber Optic Patch Cord
Use:
FTTP,CATV
Repeatability:
Additional Loss< 0.1, Return Loss< 5
Interchangeability:
Additional Loss< 0.1, Return Loss< 5
Connection Times:
>1000
Operating Temperature:
-40 ~ +75
Storage Temperature:
-40 ~ +85
Warranty:
1 Year
No. Of Fiber:
4.
Port:
Ningbo
Multimode Duplex 0.75M Lc/Pc To Lc/Pc Om3 Mm Fiber Optic Cable Patch Cord -40 85
Multimode Duplex 0.75M Lc/Pc To Lc/Pc Om3 Mm Fiber Optic Cable Patch Cord -40 85 0
Multimode Duplex 0.75M Lc/Pc To Lc/Pc Om3 Mm Fiber Optic Cable Patch Cord -40 85 1
Multimode Duplex 0.75M Lc/Pc To Lc/Pc Om3 Mm Fiber Optic Cable Patch Cord -40 85 2
Multimode Duplex 0.75M Lc/Pc To Lc/Pc Om3 Mm Fiber Optic Cable Patch Cord -40 85 3
Multimode Duplex 0.75M Lc/Pc To Lc/Pc Om3 Mm Fiber Optic Cable Patch Cord -40 85 4
Multimode Duplex 0.75M Lc/Pc To Lc/Pc Om3 Mm Fiber Optic Cable Patch Cord -40 85 5


Fiber Optic Patchcords
are components to link equipments and components in fiber optic network. There are many types according to different types of fiber optic connector including FC SV SC LC ST E2000N MTRJN MPO etc. with single mode(9/125um) and multimode(50/125 or 62.5/125). Cable jacket material can be PVC, LSZH; OFNR, OFNP etc. There are simplex, duplex, multi fibers, Ribbon fan out and bundle fiber.

● Using high precision ceramic ferrule
● Low insertion loss and high return loss
● Excellent stability and high repetition
● 100% Optic test (Insertion Loss & Return Loss)


Parameter
Unit
Mode
Type
PC
UPC
APC
Insertion Loss
dB
SM
<0.3
<0.3
<0.3
MM
<0.3
<0.3
Return Loss
dB
SM
>50
>50
>60
MM
>35
>35
Repeatability
dB
Additional loss< 0.1, return loss< 5
Interchangeability
dB
Additional loss< 0.1, return loss< 5
Connection Times
times
>1000
Operating Temperature
°C
-40 ~ +75
Storage Temperature
°C
-40 ~ +85
Test Item
Test Condition and Test Result
Wet-resistance
Condition: under temperature:85°C, relative humidity 85% for 14days.
Result: insertion losss0.1dB
Temperature Change
Condition: under temperature -40°C~+75°C, relative humidity 10 % -80 % , 42 times repetition for 14days.
Result: insertion losss0.1dB
Put in Water
Condition: under temperature 43C, PH5.5 for 7days
Result: insertion losss0.1dB
Vibrancy
Condition: Swing1.52mm, frequency 10Hz~55Hz, X, Y, Z three directions:2 hours
Result: insertion losss0.1dB
Load Bend
Condition: 0.454kg load, 100 circles
Result: insertion losss0.1dB
Load Torsion
Condition: 0.454kgload, 10 circles
Result: insertion loss s0.1dB
Tensibility
Condition: 0.23kg pull (bare fiber), 1.0kg (with shell)
Result: insertions0.1dB
Strike
Condition: High 1.8m, three directions ,8 in each direction
Result: insertion losss0.1dB
Reference Standard
BELLCORE TA-NWT-001209, IEC, GR-326-CORE standard
Multimode Duplex 0.75M Lc/Pc To Lc/Pc Om3 Mm Fiber Optic Cable Patch Cord -40 85 6
● Telecommunication Network
● Fiber Broad Band Network
● CATV system
● LAN and WAN system
● FTTP
Multimode Duplex 0.75M Lc/Pc To Lc/Pc Om3 Mm Fiber Optic Cable Patch Cord -40 85 7
Multimode Duplex 0.75M Lc/Pc To Lc/Pc Om3 Mm Fiber Optic Cable Patch Cord -40 85 8
Multimode Duplex 0.75M Lc/Pc To Lc/Pc Om3 Mm Fiber Optic Cable Patch Cord -40 85 9
Multimode Duplex 0.75M Lc/Pc To Lc/Pc Om3 Mm Fiber Optic Cable Patch Cord -40 85 10
Multimode Duplex 0.75M Lc/Pc To Lc/Pc Om3 Mm Fiber Optic Cable Patch Cord -40 85 11
Multimode Duplex 0.75M Lc/Pc To Lc/Pc Om3 Mm Fiber Optic Cable Patch Cord -40 85 12
Multimode Duplex 0.75M Lc/Pc To Lc/Pc Om3 Mm Fiber Optic Cable Patch Cord -40 85 13
Multimode Duplex 0.75M Lc/Pc To Lc/Pc Om3 Mm Fiber Optic Cable Patch Cord -40 85 14
