Fiber Optic Patch Cord LC UPC to FC UPC SM G657A1 G657A2 for Telecommunication Network

Fiber Optic Patch Cord LC UPC to FC UPC SM G657A1 G657A2 for Telecommunication Network
Fiber Optic Patch Cord LC UPC to FC UPC SM G657A1 G657A2 for Telecommunication Network
Fiber Optic Patch Cord LC UPC to FC UPC SM G657A1 G657A2 for Telecommunication Network Fiber Optic Patch Cord LC UPC to FC UPC SM G657A1 G657A2 for Telecommunication Network Fiber Optic Patch Cord LC UPC to FC UPC SM G657A1 G657A2 for Telecommunication Network Fiber Optic Patch Cord LC UPC to FC UPC SM G657A1 G657A2 for Telecommunication Network

Large Image :  Fiber Optic Patch Cord LC UPC to FC UPC SM G657A1 G657A2 for Telecommunication Network

Product Details:
Place of Origin: Zhejiang, China
Brand Name: DOWELL
Certification: CE
Model Number: DW-LUS-FUS
Payment & Shipping Terms:
Minimum Order Quantity: 1000 pieces
Delivery Time: 7-15 Days
Payment Terms: T/T, Western Union, Paypal
Supply Ability: 10000 PCS Per 7 Days
Contact Now

Fiber Optic Patch Cord LC UPC to FC UPC SM G657A1 G657A2 for Telecommunication Network

Description
Mode Type: SM, MM Fiber Type: G652D/G657A
Jacket: PVC, LSZH Connector: SC, LC, FC, ST, E2000N, MTRJN, MPO
Length: Any Length Is Customizable Color: Yellow Or Cusomized
Highlight:

5m Fiber Optic Patch Cord

,

Simplex lc patch cord

,

5m lc patch cord

SX G657A1 G657A2 LC UPC to FC UPC SM Fiber Optic Patch Cord

Fiber Optic Patchcords are components to link equipments and components in fiber optic network. There are many types according to different types of fiber optic connector including FC SV SC LC ST E2000N MTRJN MPO etc. with single mode(9/125um) and multimode (50/125 or 62.5/125). Cable jacket material can be PVC, LSZH; OFNR, OFNP etc. There are simplex, duplex, multi fibers, Ribbon fan out and bundle fiber.

Specification:

Parameter Unit Mode PC UPC APC
Type
Insertion Loss dB SM <0.3 <0.3 <0.3
MM <0.3 <0.3
Return Loss dB SM >50 >50 >60
MM >35 >35
Repeatability dB Additional loss<0.1db, return loss< 5 dB
Interchangeability dB Additional loss<0.1db, return loss< 5 dB
Connection Times times >1000
Operating Temperature °C -40 C- +75 C
Storage Temperature °C -40 C- +85 C

Application:

1. Telecommunication Network

2. Fiber Broad Band Network

3. CATV system

4. LAN and WAN system

5. FTTP

Fiber Optic Patch Cord LC UPC to FC UPC SM G657A1 G657A2 for Telecommunication Network 0

Production Flow:

Fiber Optic Patch Cord LC UPC to FC UPC SM G657A1 G657A2 for Telecommunication Network 1

Our Package:

Fiber Optic Patch Cord LC UPC to FC UPC SM G657A1 G657A2 for Telecommunication Network 2
