Black Finish 304 Stainless Steel Double Hole Fiber Cable Hangers RF 1/2" Feeder Clamp

Black Finish 304 Stainless Steel Double Hole Fiber Cable Hangers RF 1/2" Feeder Clamp
Black Finish 304 Stainless Steel Double Hole Fiber Cable Hangers RF 1/2" Feeder Clamp Black Finish 304 Stainless Steel Double Hole Fiber Cable Hangers RF 1/2" Feeder Clamp Black Finish 304 Stainless Steel Double Hole Fiber Cable Hangers RF 1/2" Feeder Clamp Black Finish 304 Stainless Steel Double Hole Fiber Cable Hangers RF 1/2" Feeder Clamp Black Finish 304 Stainless Steel Double Hole Fiber Cable Hangers RF 1/2" Feeder Clamp Black Finish 304 Stainless Steel Double Hole Fiber Cable Hangers RF 1/2" Feeder Clamp

Large Image :  Black Finish 304 Stainless Steel Double Hole Fiber Cable Hangers RF 1/2" Feeder Clamp

Product Details:
Place of Origin: Zhejiang, China
Brand Name: Dowell
Model Number: DW-1071- Feeder Clamp
Payment & Shipping Terms:
Price: $1.69/pieces 1-1999 pieces
Packaging Details: Normal Package
Supply Ability: 30000 Piece/Pieces per Week

Black Finish 304 Stainless Steel Double Hole Fiber Cable Hangers RF 1/2" Feeder Clamp

Description
Type: Feeder Clamp Use: Feeder Cable Clamp
Network: Wired LAN, FTTH Product Name: Fiber Optic Cable Suspension Clamp
Application: Telecom Cable Installation Usage: Electric Power Accessories
Operation Temp: -50 °C ~ 85 °C Warranty: 1 Year
Color: Black Material: 304 Stainless Steel
Certificate: CE ROHS ISO9001 Cable Capacity: 2,4,6,8,10,12 Etc
Size: Customize Accept Port: Ningbo

Black Finish 304 Stainless Steel Double Hole Fiber Cable Hangers RF 1/2" Feeder Clamp 0
Black Finish 304 Stainless Steel Double Hole Fiber Cable Hangers RF 1/2" Feeder Clamp 1
Black Finish 304 Stainless Steel Double Hole Fiber Cable Hangers RF 1/2" Feeder Clamp 2
Black Finish 304 Stainless Steel Double Hole Fiber Cable Hangers RF 1/2" Feeder Clamp 3
One Hole Per Layer
Two Same Holes Per Layer
Black Finish 304 Stainless Steel Double Hole Fiber Cable Hangers RF 1/2" Feeder Clamp 4
Black Finish 304 Stainless Steel Double Hole Fiber Cable Hangers RF 1/2" Feeder Clamp 5
Two Different Holes Per Layer
More options you could pick
Every Layer could be combined according customer‘s need.
Black Finish 304 Stainless Steel Double Hole Fiber Cable Hangers RF 1/2" Feeder Clamp 6
Black Finish 304 Stainless Steel Double Hole Fiber Cable Hangers RF 1/2" Feeder Clamp 7
Black Finish 304 Stainless Steel Double Hole Fiber Cable Hangers RF 1/2" Feeder Clamp 8
Black Finish 304 Stainless Steel Double Hole Fiber Cable Hangers RF 1/2" Feeder Clamp 9
Black Finish 304 Stainless Steel Double Hole Fiber Cable Hangers RF 1/2" Feeder Clamp 10
Black Finish 304 Stainless Steel Double Hole Fiber Cable Hangers RF 1/2" Feeder Clamp 11
Suitable Cables
D1---Power Cable
Cable Size
9-13mm
Suitable Cables
D2---Fiber Cable
Cable Size
4.5-7mm
Layers Quantity
Could be customized
Black Finish 304 Stainless Steel Double Hole Fiber Cable Hangers RF 1/2" Feeder Clamp 12
Black Finish 304 Stainless Steel Double Hole Fiber Cable Hangers RF 1/2" Feeder Clamp 13
This cable clamp is a sort of module assembly for fixing cables. It' s made of resist ultraviolet and enduring high temperature material. It fits for fixing the circular fiber cable of φ7mm orφ7.5mm and 3.3 square, 4 square, 6 square, 8.3 square cable. It can set three fiber cables and three cables in most. The C-shape bracket is light and terse and It' s easy to fix reliably.
Besides, it can offer a combined solution for power cables (DC) and fiber optic cables (FO). This clamp is very effective and flexible when fixing different size of DC power cables.

Clamp type
European standard
Cable Type
Power (hybrid) cable and fiber cable
Size
OD 12-22mm DC power cable
OD 7-8mm fiber cable
Number of Cables
3 power cable + 3 fiber cable
Operation Temp
-50 °C ~ 85 °C
UV Resistance
≥1000 hours
CompatibleMax Diameter
19-25mm
Compatible Min Diameter
5-7mm
Twin Plastic Clamps Material
Fiberglass reinforced PP,Black
Metal Material
Stainless steel 304 or hot galvanized
Mounting On
Steel wire cable tray
Max Stack Height
3
Vibration Survival
≥4 hours at resonant frequency
Environmental Strength Cap
Double cable weight
This Fiber Optic Cable Clamp is widely used for :
* Telecom cable
* Fiber cable
* Coaxial cable
* Feeder cable
* Hybrid cable
* Corrugated cable
* Smooth cable
* Braid cable
1. Disentwine the special bolt of the C-bracket till the ringent distance is bigger than the thick of one
side of angle iron. And then tighten the special bolt M8; (Reference torque: 15Nm)
2. Please retire the nut onto the threaded rod ,and unclench the plastic clip;
3. Disjoin the plastic clamp,plunge the Fiber cable ofφ7mm orφ7.5mm into the small hole of plastic
clamp, plunge the 3.3 square or 4 square cable into the hole of the black rubber pipe in plastic clamp.
Remove the rubber pipe from the plastic clamp for the 6 square or 8.3 square cable and plunge the
cable into the hole of plastic clamp (figure right);
4. Lock all nuts at last. (Reference torque of lock nut M8 for clamp: 11Nm)
Black Finish 304 Stainless Steel Double Hole Fiber Cable Hangers RF 1/2" Feeder Clamp 14
Black Finish 304 Stainless Steel Double Hole Fiber Cable Hangers RF 1/2" Feeder Clamp 15
Black Finish 304 Stainless Steel Double Hole Fiber Cable Hangers RF 1/2" Feeder Clamp 16
Black Finish 304 Stainless Steel Double Hole Fiber Cable Hangers RF 1/2" Feeder Clamp 17
Black Finish 304 Stainless Steel Double Hole Fiber Cable Hangers RF 1/2" Feeder Clamp 18
Black Finish 304 Stainless Steel Double Hole Fiber Cable Hangers RF 1/2" Feeder Clamp 19
Black Finish 304 Stainless Steel Double Hole Fiber Cable Hangers RF 1/2" Feeder Clamp 20
1. Q : Are you trading company or manufacturer?
A : 70% of our products we manufactured and 30% do trading for customer service
2. Q : How can you ensure the quality?
A : Good question! We are a one-stop manufacturer. We have complete facilities and over-15- years manufacturing experience to ensure product quality. And we have already passed ISO 9001 Quality Management System.
3. Q : Can you provide samples ? Is it free or extra?
A : Yes, After price confirmation , we could offer the free sample, but the shipping cost need pay for by your side.
4. Q : How long is your delivery time ?
A : In stock: In 7 days; No in stock: 15~20 days, depend on your QTY.
5. Q: Can you do OEM?
A: Yes , we can
6. Q: What is your payment term ?
A: Payment <=4000USD,100% in advance. Payment>= 4000USD, 30% TT in advance, balance before shipment.
7. Q: How we can pay?
A: TT, Western Union , Paypal ,Credit Card and LC
8. Q: Transportation?
A: Transported by DHL, UPS, EMS, Fedex, Air freight, Boat and Train
Black Finish 304 Stainless Steel Double Hole Fiber Cable Hangers RF 1/2" Feeder Clamp 21
