Fiber Optic FBT Splitter 1310/1490/1550 1*2 Coupler Blue and Orange SC/UPC 1/99 to 50/50

Large Image : Fiber Optic FBT Splitter 1310/1490/1550 1*2 Coupler Blue and Orange SC/UPC 1/99 to 50/50

Product Details:

Place of Origin:	Zhejiang, China
Brand Name:	DOWELL
Certification:	CE/RoHS/ISO9001
Model Number:	1*2 FBT Coupler-0.9mm-1m-sc/upc

Payment & Shipping Terms:

Minimum Order Quantity:	100 pieces
Price:	$2.74/pieces 100-4999 pieces
Packaging Details:	Single item
Supply Ability:	30000 Piece/Pieces per Week

Contact Now

Fiber Optic FBT Splitter 1310/1490/1550 1*2 Coupler Blue and Orange SC/UPC 1/99 to 50/50

Description

Type:	FBT Coupler	Use:	FTTH
Warranty Time:	1 Year	Network:	FTTH
Product Name:	FBT Coupler	Splitter Type:	1*2
Fiber Type:	G657A1 With 0.9mm	Connector Type:	SC/UPC Or SC/APC
Fiber Color:	Blue And Orange	Working Wavelength:	1310nm/1490nm/1550nm
Fiber Length:	1M/1.5M	Coupling Ratio:	1:99 To 50:50
Package:	Blister Or PE Bag	Port:	Ningbo

Parameter

1x2

1x4

1x8

1x16

1x32

1x64

Wavelength (nm)

1260 ～ 1650

IL (dB)

≤4.1

≤7.4

≤10.5

≤13.8

≤17.1

≤20.4

Uniformity (dB)

≤0.6

≤0.7

≤0.8

≤1.0

≤1.5

≤2.0

RL (dB)

≥50(PC), ≥55(APC)

PDL (dB)

≤0.15

≤0.2

≤0.3

Directivity (dB)

≥55

Environment

Operating Temp. (℃)

-40~85℃

Storage Temp. (℃)

-40~85℃

Humidity

≤95% (+40℃)

Atmospheric Pressure

62~106kPa

Fiber

SM G657A or customized

Connector

SC, FC, LC

Pigtail (mm)

1000, 1500, 2000 or customized

Mini Type PLC splitter is based on silicon dioxide waveguides, which is used to connect main equipment and terminal equipment in EPON, BPON and GPON network.

1×N (N≥2) PLC Splitter (with Connector) Optical Parameter

Remark:
(1) Test in room temperature and include connector.
(2) R≥55dB without connector

	nx2, nx4, nx8			1x16	2x16, nx32	nx64	Tube Type
L (mm)	55	60	60	80	100	Diameter: Φ0.9mm or customized
W (mm)	7	7	12	20	40	Material: Hytrel, PVC, LSZH or customized
H (mm)	4	4	4	6	6	Color: blue, orange, green, brown, grey, white, red, black, or customized

1. Q : Are you trading company or manufacturer?
A : 70% of our products we manufactured and 30% do trading for customer service
2. Q : How can you ensure the quality?
A : Good question! We are a one-stop manufacturer. We have complete facilities and over-15- years manufacturing experience to ensure product quality. And we have already passed ISO 9001 Quality Management System.
3. Q : Can you provide samples ? Is it free or extra?
A : Yes, After price confirmation , we could offer the free sample, but the shipping cost need pay for by your side.
4. Q : How long is your delivery time ?
A : In stock: In 7 days; No in stock: 15~20 days, depend on your QTY.
5. Q: Can you do OEM?
A: Yes , we can
6. Q: What is your payment term ?
A: Payment <=4000USD，100% in advance. Payment>= 4000USD, 30% TT in advance, balance before shipment.
7. Q: How we can pay?
A: TT, Western Union , Paypal ,Credit Card and LC
8. Q: Transportation?
A: Transported by DHL, UPS, EMS, Fedex, Air freight, Boat and Train
