Product Details
Place of Origin: Zhejiang, China
Brand Name: DOWELL
Model Number: DW-250D-U
Payment & Shipping Terms
Price: $0.40/pieces 1-4999 pieces
Packaging Details: Single item
Supply Ability: 30000 Piece/Pieces per Week
Type: |
Fiber Adapter & Connectors |
Use: |
FTTx, Data Room Transformation |
Warranty Time: |
1 Year |
Network: |
FTTX |
Mode: |
SM SC/UPC |
Operating Temperature: |
-40~+85 ℃ |
Return Loss: |
≤ -55dB |
Insertion Loss: |
0.3dB |
Operation Time: |
About 15s |
Size: |
50*8.7*8.3 Mm Without Dust Cap |
Application: |
FTTH FTTxFTTB Network |
Item1: |
SC/UPC |
Item2: |
SC/APC |
Length: |
55mm/60mm |
Port: |
Ningbo |
Type: |
Fiber Adapter & Connectors |
Use: |
FTTx, Data Room Transformation |
Warranty Time: |
1 Year |
Network: |
FTTX |
Mode: |
SM SC/UPC |
Operating Temperature: |
-40~+85 ℃ |
Return Loss: |
≤ -55dB |
Insertion Loss: |
0.3dB |
Operation Time: |
About 15s |
Size: |
50*8.7*8.3 Mm Without Dust Cap |
Application: |
FTTH FTTxFTTB Network |
Item1: |
SC/UPC |
Item2: |
SC/APC |
Length: |
55mm/60mm |
Port: |
Ningbo |
Cable Scope | ① 3.0 x 2.0 mm bow-type drop cable ② 2.0 x 1.6 mm drop cable ③Φ0.9mm fiber cable | Size | 55 x 8.7 x 8.3 mm 60 x 8.7 x 8.3 mm without dust cap |
Fiber Diameter | 125μm ( 652 & 657 ) | Coating Diameter | 250μm |
Mode | SM SC/APC | Operation Time | about 15s（exclude fiber presetting) |
Insertion Loss | ≤ 0.3dB（1310nm & 1550nm) | Return Loss | ≥ 55dB |
Success Rate | > 98% | Reusable Times | > 10 times |
Tighten Strength of Naked Fiber | > 5 N | Tensile Strength | > 50 N |
Mechanical Durability (500 times) | IL ≤ 0.3dB | Drop Test (4m concrete floor, once each direction, three times total) | IL ≤ 0.3dB |
Temperature | -40℃ ~ +85℃ | On-line Tensile Strength Test (20 N) | IL ≤ 0.3dB |
