Small Cable Dry Super-Mini Straight Connector 25-pair Splicing Module 1.65mm

Certification
China ningbo dowel tech co,.ltd certification
I'm Online Chat Now

Small Cable Dry Super-Mini Straight Connector 25-pair Splicing Module 1.65mm

Small Cable Dry Super-Mini Straight Connector 25-pair Splicing Module 1.65mm
Small Cable Dry Super-Mini Straight Connector 25-pair Splicing Module 1.65mm Small Cable Dry Super-Mini Straight Connector 25-pair Splicing Module 1.65mm Small Cable Dry Super-Mini Straight Connector 25-pair Splicing Module 1.65mm Small Cable Dry Super-Mini Straight Connector 25-pair Splicing Module 1.65mm Small Cable Dry Super-Mini Straight Connector 25-pair Splicing Module 1.65mm Small Cable Dry Super-Mini Straight Connector 25-pair Splicing Module 1.65mm

Large Image :  Small Cable Dry Super-Mini Straight Connector 25-pair Splicing Module 1.65mm

Product Details:
Place of Origin: China,zhejiang
Brand Name: DOWELL
Model Number: DW-4000D
Payment & Shipping Terms:
Minimum Order Quantity: 1000 pieces
Price: $0.84/pieces 1000-9999 pieces

Small Cable Dry Super-Mini Straight Connector 25-pair Splicing Module 1.65mm

Description
Type: Mini Splicing Module Max Insulation Diameter (mm): 1.65
Cable Style And Wire Diameter: 0.65-0.32mm(22-28AWG) Operating Temperature: -30℃~+80℃

Small Cable Dry Super-Mini Straight Connector 25-pair Splicing Module 1.65mm 0
Small Cable Dry Super-Mini Straight Connector 25-pair Splicing Module 1.65mm 1
Small Cable Dry Super-Mini Straight Connector 25-pair Splicing Module 1.65mm 2
Small Cable Dry Super-Mini Straight Connector 25-pair Splicing Module 1.65mm 3
Small Cable Dry Super-Mini Straight Connector 25-pair Splicing Module 1.65mm 4
Small Cable Dry Super-Mini Straight Connector 25-pair Splicing Module 1.65mm 5
Specifications
Max insulation diameter (mm)
1.65
Cable style and wire diameter
0.65-0.32mm(22-28AWG)
Environment characteristic
Environment chaStorage Temperature Range
-40℃~+120℃
Operating Temperature Range
-30℃~+80℃
Relative Humidity
<90%(at20℃)
Atemospheric Pressure
70KPa~106KPa
Mechanical Performance
Plastic Housing
PC (UL 94v-0)
Contacts
Tinned Phosphor Bronze
Cutting blades leftover cable
Stainless steel
Wire Insertion Force
45N Typical
Wire Pull out Force
40N Typical
Breaking strength or slip conductor
> 75% Wire breaking strength
Use Times
>100
Electrical Performance
Insulation Resistance
R≥10000M Ohm
Contact Resistance
The vary of the contact resistance ≤1m Ohm
Dielectric Strength
2000V DC 60s can't spark over and haven't fly arc
Constant Current
5KA 8/20u Sec
Surge Current
10KA 8/20u Sec
Small Cable Dry Super-Mini Straight Connector 25-pair Splicing Module 1.65mm 6
Small Cable Dry Super-Mini Straight Connector 25-pair Splicing Module 1.65mm 7
Small Cable Dry Super-Mini Straight Connector 25-pair Splicing Module 1.65mm 8
Small Cable Dry Super-Mini Straight Connector 25-pair Splicing Module 1.65mm 9
Small Cable Dry Super-Mini Straight Connector 25-pair Splicing Module 1.65mm 10
Small Cable Dry Super-Mini Straight Connector 25-pair Splicing Module 1.65mm 11
Small Cable Dry Super-Mini Straight Connector 25-pair Splicing Module 1.65mm 12
1. Q : Are you trading company or manufacturer?
A : 70% of our products we manufactured and 30% do trading for customer service
2. Q : How can you ensure the quality?
A : Good question! We are a one-stop manufacturer. We have complete facilities and over-15- years manufacturing experience to ensure product quality. And we have already passed ISO 9001 Quality Management System.
3. Q : Can you provide samples ? Is it free or extra?
A : Yes, After price confirmation , we could offer the free sample, but the shipping cost need pay for by your side.
4. Q : How long is your delivery time ?
A : In stock: In 7 days; No in stock: 15~20 days, depend on your QTY.
5. Q: Can you do OEM?
A: Yes , we can
6. Q: What is your payment term ?
A: Payment <=4000USD,100% in advance. Payment>= 4000USD, 30% TT in advance, balance before shipment.
7. Q: How we can pay?
A: TT, Western Union , Paypal ,Credit Card and LC
8. Q: Transportation?
A: Transported by DHL, UPS, EMS, Fedex, Air freight, Boat and Train
