Product Details
Place of Origin: Zhejiang, China
Brand Name: DOWELL
Model Number: DW-C1X16
Payment & Shipping Terms
Minimum Order Quantity: 100 pieces
Price: $6.99 - $9.99/pieces
Type: |
1x16 Cassette Type |
Use: |
EPON, BPON And GPON Network. |
Warranty Time: |
1 Year |
Network: |
FTTH |
Connector: |
SC, FC, LC |
Atmospheric Pressure: |
62~106kPa |
Storage Temp.: |
- 40°C To +85°C |
RL (dB): |
≥50(PC), ≥55(APC) |
Size: |
130x100x50mm |
Type: |
1x16 Cassette Type |
Use: |
EPON, BPON And GPON Network. |
Warranty Time: |
1 Year |
Network: |
FTTH |
Connector: |
SC, FC, LC |
Atmospheric Pressure: |
62~106kPa |
Storage Temp.: |
- 40°C To +85°C |
RL (dB): |
≥50(PC), ≥55(APC) |
Size: |
130x100x50mm |
Parameter | 1x2 | 1x4 | 1x8 | 1x16 | 1x32 | 1x64 | |||||||
Wavelength (nm) | 1260 ～ 1650 | ||||||||||||
IL (dB) | ≤4.1 | ≤7.4 | ≤10.5 | ≤13.8 | ≤17.1 | ≤20.4 | |||||||
Uniformity (dB) | ≤0.6 | ≤0.7 | ≤0.8 | ≤1.0 | ≤1.5 | ≤2.0 | |||||||
RL (dB) | ≥50(PC), ≥55(APC) | ||||||||||||
PDL (dB) | ≤0.15 | ≤0.2 | ≤0.2 | ≤0.3 | ≤0.3 | ≤0.3 | |||||||
Directivity (dB) | ≥55 | ≥55 | ≥55 | ≥55 | ≥55 | ≥55 | |||||||
Environment | Operating Temp. (℃) | -40~85℃ | |||||||||||
Storage Temp. (℃) | -40~85℃ | ||||||||||||
Humidity | ≤95% (+40℃) | ||||||||||||
Atmospheric Pressure | 62~106kPa | ||||||||||||
Fiber | SM G657A or customized | ||||||||||||
Connector | SC, FC, LC | ||||||||||||
Pigtail (mm) | 1000, 1500, 2000 or customized | ||||||||||||
