GJXFH 1 2 4 Core Self-Supporting Fiber Optic Cable for FTTH Round Cable in White/Black

Certification
China ningbo dowel tech co,.ltd certification
I'm Online Chat Now

GJXFH 1 2 4 Core Self-Supporting Fiber Optic Cable for FTTH Round Cable in White/Black

GJXFH 1 2 4 Core Self-Supporting Fiber Optic Cable for FTTH Round Cable in White/Black
GJXFH 1 2 4 Core Self-Supporting Fiber Optic Cable for FTTH Round Cable in White/Black GJXFH 1 2 4 Core Self-Supporting Fiber Optic Cable for FTTH Round Cable in White/Black GJXFH 1 2 4 Core Self-Supporting Fiber Optic Cable for FTTH Round Cable in White/Black GJXFH 1 2 4 Core Self-Supporting Fiber Optic Cable for FTTH Round Cable in White/Black GJXFH 1 2 4 Core Self-Supporting Fiber Optic Cable for FTTH Round Cable in White/Black GJXFH 1 2 4 Core Self-Supporting Fiber Optic Cable for FTTH Round Cable in White/Black

Large Image :  GJXFH 1 2 4 Core Self-Supporting Fiber Optic Cable for FTTH Round Cable in White/Black

Product Details:
Place of Origin: Zhejiang, China
Brand Name: DOWELL
Model Number: DW-GJXFH
Payment & Shipping Terms:
Price: $11.99 - $15.99/kilometers

GJXFH 1 2 4 Core Self-Supporting Fiber Optic Cable for FTTH Round Cable in White/Black

Description
Type: Fiber Optic Cable Drum Size: 300x300x300
Gross Weight: 8.50kg/km Fiber Type: G652D/ G657A
Color: White/black

GJXFH 1 2 4 Core Self-Supporting Fiber Optic Cable for FTTH Round Cable in White/Black 0
GJXFH 1 2 4 Core Self-Supporting Fiber Optic Cable for FTTH Round Cable in White/Black 1
GJXFH 1 2 4 Core Self-Supporting Fiber Optic Cable for FTTH Round Cable in White/Black 2
GJXFH 1 2 4 Core Self-Supporting Fiber Optic Cable for FTTH Round Cable in White/Black 3
GJXFH 1 2 4 Core Self-Supporting Fiber Optic Cable for FTTH Round Cable in White/Black 4
Fiber Count
Cable Diameter mm
Cable Weight Kg/km
Tensile Strength Long/Short Term N
Crush Resistance Long/Short Term N/100m
Bending Radius Static/Dynamic mm
1
(2.0±0.2)×(3.0±0.2)
8.5
60/120
1000/2200
20D/40D
2
(2.0±0.2)×(3.0±0.2)
8.5
60/120
1000/2200
20D/40D
4
(2.0±0.2)×(3.0±0.2)
8.5
60/120
1000/2200
20D/40D
6
(2.5±0.2)×(4.0±0.2)
9.0
60/120
1000/2200
20D/40D
G.652
G.657
50/125um
62.5/125um
Attenuation (+20 )
@850nm
≤3.5 dB/km
≤3.5 dB/km
@1300nm
≤1.5 dB/km
≤1.5 dB/km
@1310nm
≤0.35 dB/km
≤0.24dB/km
@1550nm
≤0.30 dB/km
≤0.22 dB/km
Bandwidth (Class A 850nm
@850nm
≥500 Mhz.km
≥200 Mhz.km
@1300nm
≥500 Mhz.km
≥500 Mhz.km
Numerical aperture
0.200±0.015NA
0.275±0.015NA
Cable Cutoff Wavelength
≤1260nm
≤1260nm
No. of  Fiber
1F
Gross weight
8.50kg/km
SM Fiber
Fiber Type
G652D/ G657A
MFD
8 8 10.4um
Cladding diameter
125±0.7um
Cladding non-circularity
≤0.7%
Coating diameter
242±7um
Fiber color
standard spectrum
Strength member
Material
FRP
Color
white
Diameter
0.5mm
Qty
2
Tight buffer
Material
Nylon
Color
white
Diameter
0.9mm
Out sheath
Material
LSZH
Color
white/black
Diameter
(2.0±0.1) × (3.0±0.1)
Thickness
≧0.5mm
GJXFH 1 2 4 Core Self-Supporting Fiber Optic Cable for FTTH Round Cable in White/Black 5
GJXFH 1 2 4 Core Self-Supporting Fiber Optic Cable for FTTH Round Cable in White/Black 6
GJXFH 1 2 4 Core Self-Supporting Fiber Optic Cable for FTTH Round Cable in White/Black 7
GJXFH 1 2 4 Core Self-Supporting Fiber Optic Cable for FTTH Round Cable in White/Black 8
GJXFH 1 2 4 Core Self-Supporting Fiber Optic Cable for FTTH Round Cable in White/Black 9
GJXFH 1 2 4 Core Self-Supporting Fiber Optic Cable for FTTH Round Cable in White/Black 10
GJXFH 1 2 4 Core Self-Supporting Fiber Optic Cable for FTTH Round Cable in White/Black 11
1. Q : Are you trading company or manufacturer?
A : 70% of our products we manufactured and 30% do trading for customer service
2. Q : How can you ensure the quality?
A : Good question! We are a one-stop manufacturer. We have complete facilities and over-15- years manufacturing experience to ensure product quality. And we have already passed ISO 9001 Quality Management System.
3. Q : Can you provide samples ? Is it free or extra?
A : Yes, After price confirmation , we could offer the free sample, but the shipping cost need pay for by your side.
4. Q : How long is your delivery time ?
A : In stock: In 7 days; No in stock: 15~20 days, depend on your QTY.
5. Q: Can you do OEM?
A: Yes , we can
6. Q: What is your payment term ?
A: Payment <=4000USD,100% in advance. Payment>= 4000USD, 30% TT in advance, balance before shipment.
7. Q: How we can pay?
A: TT, Western Union , Paypal ,Credit Card and LC
8. Q: Transportation?
A: Transported by DHL, UPS, EMS, Fedex, Air freight, Boat and Train
