MDF7100 Siemens Termination Block 100 pair With 5 pair Protector Over-Voltage

China MDF7100 Siemens Termination Block 100 pair With 5 pair Protector Over-Voltage supplier
MDF7100 Siemens Termination Block 100 pair With 5 pair Protector Over-Voltage supplier MDF7100 Siemens Termination Block 100 pair With 5 pair Protector Over-Voltage supplier MDF7100 Siemens Termination Block 100 pair With 5 pair Protector Over-Voltage supplier MDF7100 Siemens Termination Block 100 pair With 5 pair Protector Over-Voltage supplier

Large Image :  MDF7100 Siemens Termination Block 100 pair With 5 pair Protector Over-Voltage

Product Details:

Place of Origin: China
Brand Name: YUHUI
Certification: ISO,RHOS,UL,CE
Model Number: YH-6004

Payment & Shipping Terms:

Minimum Order Quantity: 100pieces
Price: Negotiation
Packaging Details: 1piece/box
Delivery Time: 30days
Payment Terms: TT,LC,West Union
Supply Ability: 500pieces/day
Contact Now
Detailed Product Description
Size: H/W/D=290/90.5/150mm MDF: Double Side Main Distribution Frame
Replaced Of: Siemens MDF 7100 Accessories: Consists

 MDF7100 Siemens Termination Block 100 pair With 5 pair Protector Over-Voltage



Quick Detail:



1, Material: PBT or ABS(UL94V-0)

2, Contact: Phosphor Bronze

3, Silver Plating: 0.5 um1.25 um5 um

4, MDF7100-100 Terminal block H/W/D=290/90.5/150mm

5, With Protector 2pole arrester for 230V over-voltage

6. 100% test passed

7. C39407-A139-A12 termination tool available





Description:



Block Size: H/W/D=290/90.5/150mm

The Main distribution frame consists of the frame, protection blocks, test blocks, protector modules, alarm system and other accessories labeling,number plug,dummy plug.


Wholly module structure which make it ease of access for installers effectively isolate equipment and maintain personnel prevent from damage which cause by lighting or other matter.


Mechanical Performance
Plastic material: ABS&PBT(UL94V-0)
Contact material: Phosphor Bronze.
Surface Plating Silver(0.5um-5um)
Earth bar: Phosphor Bronze.
Surface Plating nickel



Protector

MDF7100 Siemens Termination Block 100 pair With 5 pair Protector Over-Voltage



Punch tool

MDF7100 Siemens Termination Block 100 pair With 5 pair Protector Over-Voltage


Applications:



High speed LAN and WAN systems,used to protect the telecom equipment from damage of lightning,over voltage and over currence.





Specifications :


Mechanical Performance Plastic material: ABS&PBT(UL94V-0)
Contact material: Phosphor Bronze.
Surface Plating Silver(0.5um-5um)
Earth bar: Phosphor Bronze.Surface Plating nickel
Environment Characteristic Storage Tempreture: 40 to 70°C
Operating Temperature : 10 to 60°C
Relative Humidity: 95%, noncondition
Electrical Performance Insulation resistance: 1000 Mohms minimum
Contact resistance :5 mohms maximum
Dielectric intensity: 1200V DC 60s can't spark over and haven't fly arc
