Product Details
Place of Origin: Zhejiang, China
Brand Name: DOWELL
Model Number: DW-FAC-SCU
Payment & Shipping Terms
Minimum Order Quantity: 500 pieces
Price: $0.30 - $0.40/pieces
Packaging Details: Single item
Supply Ability: 30000 Piece/Pieces per Week
Type: |
SC UPC Mechanical Connector |
Use: |
FTTX,FTTH |
Warranty Time: |
1 Year |
Network: |
Network, FTTH |
Mode: |
SM |
Insertion Loss: |
≤ 0.3dB |
Return Loss Of Pigtail: |
≥50dB |
Size: |
51*9*7.55mm |
Coating Diameter: |
250μm |
Port: |
Ningbo |
Type: |
SC UPC Mechanical Connector |
Use: |
FTTX,FTTH |
Warranty Time: |
1 Year |
Network: |
Network, FTTH |
Mode: |
SM |
Insertion Loss: |
≤ 0.3dB |
Return Loss Of Pigtail: |
≥50dB |
Size: |
51*9*7.55mm |
Coating Diameter: |
250μm |
Port: |
Ningbo |
Item | Parameter |
Size | 51*9*7.55mm |
Cable Scope | 3.0 x 2.0 mm and 1.6*2.0mm Bow-type Drop Cable |
Fiber Diameter | 125μm ( G652D & 657A1.A2 ) |
Coating Diameter | 250μm |
Mode | SM SC/UPC |
Operation Time | about 15s (exclude fiber presetting) |
Insertion Loss | ≤ 0.3dB (1310nm & 1550nm) |
Return Loss | ≥50dB for UPC, ≥55dB for APC |
Success Rate | >98% |
Reusable Times | >10 times |
Tensile Strength | >5 N |
Tighten Strength of Coating | >10 N |
Temperature | -40 - +85 C |
On-line Tensile Strength Test (20 N) | IL ≤ 0.3dB |
Mechanical Durability（500 times) | IL ≤ 0.3dB |
Drop Test (4m concrete floor, once each direction, three times total) | IL ≤ 0.3dB |
