Fiber Optic Fast Connector SC/APC UPC Quick Assembly T-Click T-Rosca Return Loss ≤ -55dB 1

Fiber Optic Fast Connector SC/APC UPC Quick Assembly T-Click T-Rosca Return Loss ≤ -55dB 1
Fiber Optic Fast Connector SC/APC UPC Quick Assembly T-Click T-Rosca Return Loss ≤ -55dB 1 Fiber Optic Fast Connector SC/APC UPC Quick Assembly T-Click T-Rosca Return Loss ≤ -55dB 1 Fiber Optic Fast Connector SC/APC UPC Quick Assembly T-Click T-Rosca Return Loss ≤ -55dB 1 Fiber Optic Fast Connector SC/APC UPC Quick Assembly T-Click T-Rosca Return Loss ≤ -55dB 1 Fiber Optic Fast Connector SC/APC UPC Quick Assembly T-Click T-Rosca Return Loss ≤ -55dB 1 Fiber Optic Fast Connector SC/APC UPC Quick Assembly T-Click T-Rosca Return Loss ≤ -55dB 1

Large Image :  Fiber Optic Fast Connector SC/APC UPC Quick Assembly T-Click T-Rosca Return Loss ≤ -55dB 1

Product Details:
Place of Origin: Zhejiang, China
Brand Name: DOWELL
Model Number: DW-FAC-BU
Payment & Shipping Terms:
Price: $0.45/pieces 1-4999 pieces
Packaging Details: Single item
Supply Ability: 30000 Piece/Pieces per Week
Contact Now

Fiber Optic Fast Connector SC/APC UPC Quick Assembly T-Click T-Rosca Return Loss ≤ -55dB 1

Description
Type: Fiber Adapter & Connectors Use: FTTx, Data Room Transformation
Warranty Time: 1 Year Network: FTTX
Mode: SM SC/APC Operating Temperature: -40~+85 ℃
Return Loss: ≤ -55dB Insertion Loss: 0.3dB
Operation Time: About 15s Size: 50*8.7*8.3 Mm Without Dust Cap
Application: FTTH FTTxFTTB Network Item1: SC/UPC
Item2: SC/APC Length: 55mm/60mm
Port: Ningbo

Fiber Optic Fast Connector SC/APC UPC Quick Assembly T-Click T-Rosca Return Loss ≤ -55dB 1 0
Products Description
Fiber Optic Fast Connector SC/APC UPC Quick Assembly T-Click T-Rosca Return Loss ≤ -55dB 1 1
Fiber Optic Fast Connector SC/APC UPC Quick Assembly T-Click T-Rosca Return Loss ≤ -55dB 1 2

DW-FAC-B-U SC /APC Fast Connector
Fiber Optic Fast Connector SC/APC UPC Quick Assembly T-Click T-Rosca Return Loss ≤ -55dB 1 3
DW-FAC-B-A SC /APC Fast Connector

Fiber Optic Fast Connector SC/APC UPC Quick Assembly T-Click T-Rosca Return Loss ≤ -55dB 1 4

DW-FAC-SCA SC /APC Fast Connector
Fiber Optic Fast Connector SC/APC UPC Quick Assembly T-Click T-Rosca Return Loss ≤ -55dB 1 5

DW-FAC-SCU SC /UPC Fast Connector
Fiber Optic Fast Connector SC/APC UPC Quick Assembly T-Click T-Rosca Return Loss ≤ -55dB 1 6
SC APC Field Assembly Connector
Fiber Optic Fast Connector SC/APC UPC Quick Assembly T-Click T-Rosca Return Loss ≤ -55dB 1 7
SC UPC Field Assembly Connector
Fiber Optic Fast Connector SC/APC UPC Quick Assembly T-Click T-Rosca Return Loss ≤ -55dB 1 8

DW-250P-A SC APC Fast Connector
Fiber Optic Fast Connector SC/APC UPC Quick Assembly T-Click T-Rosca Return Loss ≤ -55dB 1 9

DW-250P-U SC UPC Fast Connector
Fiber Optic Fast Connector SC/APC UPC Quick Assembly T-Click T-Rosca Return Loss ≤ -55dB 1 10

DW-FLA LC APC Fast Connector
Fiber Optic Fast Connector SC/APC UPC Quick Assembly T-Click T-Rosca Return Loss ≤ -55dB 1 11

DW-FLU LC UPC Fast Connector
Fiber Optic Fast Connector SC/APC UPC Quick Assembly T-Click T-Rosca Return Loss ≤ -55dB 1 12
Fiber Optic Fast Connector SC/APC UPC Quick Assembly T-Click T-Rosca Return Loss ≤ -55dB 1 13
Fiber Optic Fast Connector SC/APC UPC Quick Assembly T-Click T-Rosca Return Loss ≤ -55dB 1 14
DW-1041-A SC APC Mechanical Fiber Optic Connector
Cable Scope
① 3.0 x 2.0 mm bow-type drop cable ② 2.0 x 1.6 mm drop cable ③Φ0.9mm fiber cable
Size
55 x 8.7 x 8.3 mm
60 x 8.7 x 8.3 mm
without dust cap
Fiber Diameter
125μm ( 652 & 657 )
Coating Diameter
250μm
Mode
SM SC/APC
Operation Time
about 15s（exclude fiber presetting)
Insertion Loss
 ≤ 0.3dB（1310nm & 1550nm)
Return Loss
≥ 55dB
Success Rate
> 98%
Reusable Times
> 10 times
Tighten Strength of Naked Fiber
> 5 N
Tensile Strength
> 50 N
Mechanical Durability (500 times)
IL ≤ 0.3dB
Drop Test (4m concrete floor, once each direction, three times total)
IL ≤ 0.3dB
Temperature
 -40℃ ~ +85℃
On-line Tensile Strength Test (20 N)
IL ≤ 0.3dB
Fiber Optic Fast Connector SC/APC UPC Quick Assembly T-Click T-Rosca Return Loss ≤ -55dB 1 15
Fiber Optic Fast Connector SC/APC UPC Quick Assembly T-Click T-Rosca Return Loss ≤ -55dB 1 16
Fiber Optic Fast Connector SC/APC UPC Quick Assembly T-Click T-Rosca Return Loss ≤ -55dB 1 17
Fiber Optic Fast Connector SC/APC UPC Quick Assembly T-Click T-Rosca Return Loss ≤ -55dB 1 18
FTTx, Data Room Transformation
Fiber Optic Fast Connector SC/APC UPC Quick Assembly T-Click T-Rosca Return Loss ≤ -55dB 1 19
Fiber Optic Fast Connector SC/APC UPC Quick Assembly T-Click T-Rosca Return Loss ≤ -55dB 1 20
Customized Service
Fiber Optic Fast Connector SC/APC UPC Quick Assembly T-Click T-Rosca Return Loss ≤ -55dB 1 21
Fiber Optic Fast Connector SC/APC UPC Quick Assembly T-Click T-Rosca Return Loss ≤ -55dB 1 22
Customer Reviews
Fiber Optic Fast Connector SC/APC UPC Quick Assembly T-Click T-Rosca Return Loss ≤ -55dB 1 23
Company Profile
Fiber Optic Fast Connector SC/APC UPC Quick Assembly T-Click T-Rosca Return Loss ≤ -55dB 1 24
Fiber Optic Fast Connector SC/APC UPC Quick Assembly T-Click T-Rosca Return Loss ≤ -55dB 1 25
Fiber Optic Fast Connector SC/APC UPC Quick Assembly T-Click T-Rosca Return Loss ≤ -55dB 1 26
Fiber Optic Fast Connector SC/APC UPC Quick Assembly T-Click T-Rosca Return Loss ≤ -55dB 1 27
Fiber Optic Fast Connector SC/APC UPC Quick Assembly T-Click T-Rosca Return Loss ≤ -55dB 1 28
FAQ
1. Q : Are you trading company or manufacturer?
 A : 70% of our products we manufactured and 30% do trading for customer service
2. Q : How can you ensure the quality?
 A : Good question! We are a one-stop manufacturer. We have complete facilities and over-15- years manufacturing experience to ensure product quality. And we have already passed ISO 9001 Quality Management System.
3. Q : Can you provide samples ? Is it free or extra?
 A : Yes, After price confirmation , we could offer the free sample, but the shipping cost need pay for by your side.
4. Q : How long is your delivery time ?
 A : In stock: In 7 days; No in stock: 15~20 days, depend on your QTY.
5. Q: Can you do OEM?
 A: Yes , we can
6. Q: What is your payment term ?
 A: Payment <=4000USD，100% in advance. Payment>= 4000USD, 30% TT in advance, balance before shipment.
7. Q: How we can pay?
 A: TT, Western Union , Paypal ,Credit Card and LC
8. Q: Transportation?
 A: Transported by DHL, UPS, EMS, Fedex, Air freight, Boat and Train
