SC/APC Fiber Optics Equipment for FTTH Network Mechanical Splice Fast Connectors

Product Details

Place of Origin: Zhejiang, China

Brand Name: DOWELL

Model Number: DW-FAC-BU

Payment & Shipping Terms

Price: $0.45/pieces 1-4999 pieces

Packaging Details: Single item

Supply Ability: 30000 Piece/Pieces per Week

Get Best Price
Highlight:
Type:
Fiber Adapter & Connectors
Use:
FTTx, Data Room Transformation
Warranty Time:
1 Year
Network:
FTTH
Mode:
SM SC/APC
Operating Temperature:
-40~+85 ℃
Return Loss:
≤ -55dB
Insertion Loss:
0.3dB
Operation Time:
About 15s
Size:
50*8.7*8.3 Mm Without Dust Cap
Application:
FTTH FTTxFTTB Network
Item1:
SC/UPC
Item2:
SC/APC
Length:
55mm/60mm
Port:
Ningbo
Type:
Fiber Adapter & Connectors
Use:
FTTx, Data Room Transformation
Warranty Time:
1 Year
Network:
FTTH
Mode:
SM SC/APC
Operating Temperature:
-40~+85 ℃
Return Loss:
≤ -55dB
Insertion Loss:
0.3dB
Operation Time:
About 15s
Size:
50*8.7*8.3 Mm Without Dust Cap
Application:
FTTH FTTxFTTB Network
Item1:
SC/UPC
Item2:
SC/APC
Length:
55mm/60mm
Port:
Ningbo
SC/APC Fiber Optics Equipment for FTTH Network Mechanical Splice Fast Connectors
SC/APC Fiber Optics Equipment for FTTH Network Mechanical Splice Fast Connectors 0
Products Description
SC/APC Fiber Optics Equipment for FTTH Network Mechanical Splice Fast Connectors 1
SC/APC Fiber Optics Equipment for FTTH Network Mechanical Splice Fast Connectors 2

DW-FAC-B-U SC /APC Fast Connector
SC/APC Fiber Optics Equipment for FTTH Network Mechanical Splice Fast Connectors 3
DW-FAC-B-A SC /APC Fast Connector

SC/APC Fiber Optics Equipment for FTTH Network Mechanical Splice Fast Connectors 4

DW-FAC-SCA SC /APC Fast Connector
SC/APC Fiber Optics Equipment for FTTH Network Mechanical Splice Fast Connectors 5

DW-FAC-SCU SC /UPC Fast Connector
SC/APC Fiber Optics Equipment for FTTH Network Mechanical Splice Fast Connectors 6
SC APC Field Assembly Connector
SC/APC Fiber Optics Equipment for FTTH Network Mechanical Splice Fast Connectors 7
SC UPC Field Assembly Connector
SC/APC Fiber Optics Equipment for FTTH Network Mechanical Splice Fast Connectors 8

DW-250P-A SC APC Fast Connector
SC/APC Fiber Optics Equipment for FTTH Network Mechanical Splice Fast Connectors 9

DW-250P-U SC UPC Fast Connector
SC/APC Fiber Optics Equipment for FTTH Network Mechanical Splice Fast Connectors 10

DW-FLA LC APC Fast Connector
SC/APC Fiber Optics Equipment for FTTH Network Mechanical Splice Fast Connectors 11

DW-FLU LC UPC Fast Connector
SC/APC Fiber Optics Equipment for FTTH Network Mechanical Splice Fast Connectors 12
SC/APC Fiber Optics Equipment for FTTH Network Mechanical Splice Fast Connectors 13
SC/APC Fiber Optics Equipment for FTTH Network Mechanical Splice Fast Connectors 14
DW-1041-A SC APC Mechanical Fiber Optic Connector
Cable Scope
① 3.0 x 2.0 mm bow-type drop cable ② 2.0 x 1.6 mm drop cable ③Φ0.9mm fiber cable
Size
55 x 8.7 x 8.3 mm
60 x 8.7 x 8.3 mm
without dust cap
Fiber Diameter
125μm ( 652 & 657 )
Coating Diameter
250μm
Mode
SM SC/APC
Operation Time
about 15s(exclude fiber presetting)
Insertion Loss
 ≤ 0.3dB(1310nm & 1550nm)
Return Loss
≥ 55dB
Success Rate
> 98%
Reusable Times
> 10 times
Tighten Strength of Naked Fiber
> 5 N
Tensile Strength
> 50 N
Mechanical Durability (500 times)
IL ≤ 0.3dB
Drop Test (4m concrete floor, once each direction, three times total)
IL ≤ 0.3dB
Temperature
 -40℃ ~ +85℃
On-line Tensile Strength Test (20 N)
IL ≤ 0.3dB
