1x2 1x4 1x8 1x16 Box Fiber Optic Plc Splitter Sc Splitter Plug-in Type Fiber Splitter

Name: 1x2 1x4 1x8 1x16 Box Fiber Optic Plc Splitter Sc Splitter Plug-in Type Fiber Splitter
Brand: DOWELL
SKU: DW-C1X8
Price: 4.56 USD
Availability: InStock
Rating: 4.9 (151 reviews)

Product Details

Place of Origin: Zhejiang, China

Brand Name: DOWELL

Model Number: DW-C1X8

Payment & Shipping Terms

Price: $4.56/pieces 1-199 pieces

Packaging Details: Single item

Supply Ability: 30000 Piece/Pieces per Week

Get Best Price

Product Details

Product Description

Highlight:

Type:	1x8 Cassette Type	Use:	EPON, BPON And GPON Network.
Warranty Time:	1 Year	Network:	FTTH
Connector:	SC, FC, LC	Atmospheric Pressure:	62~106kPa
Storage Temp.:	- 40°C To +85°C	IL (dB):	≤7.4
Uniformity (dB):	≤0.7	RL (dB):	≥50(PC), ≥55(APC)
PDL (dB):	≤0.2	Port:	Ningbo

Type:	1x8 Cassette Type
Use:	EPON, BPON And GPON Network.
Warranty Time:	1 Year
Network:	FTTH
Connector:	SC, FC, LC
Atmospheric Pressure:	62~106kPa
Storage Temp.:	- 40°C To +85°C
IL (dB):	≤7.4
Uniformity (dB):	≤0.7
RL (dB):	≥50(PC), ≥55(APC)
PDL (dB):	≤0.2
Port:	Ningbo

1x2 1x4 1x8 1x16 Box Fiber Optic Plc Splitter Sc Splitter Plug-in Type Fiber Splitter

Cassette Type PLC splitter is based on silicon dioxide waveguides, which is used to connect main equipment and terminal equipment in EPON, BPON and GPON network.

1×N (N≥2) PLC Splitter (with Connector) Optical Parameter

Parameter

1x2

1x4

1x8

1x16

1x32

1x64

Wavelength (nm)

1260 ～ 1650

IL (dB)

≤4.1

≤7.4

≤10.5

≤13.8

≤17.1

≤20.4

Uniformity (dB)

≤0.6

≤0.7

≤0.8

≤1.0

≤1.5

≤2.0

RL (dB)

≥50(PC), ≥55(APC)

PDL (dB)

≤0.15

≤0.2

≤0.3

Directivity (dB)

≥55

Environment

Operating Temp. (℃)

-40~85℃

Storage Temp. (℃)

-40~85℃

Humidity

≤95% (+40℃)

Atmospheric Pressure

62~106kPa

Fiber

SM G657A or customized

Connector

SC, FC, LC

Pigtail (mm)

1000, 1500, 2000 or customized

Remark:
(1) Test in room temperature and include connector.
(2) R≥55dB without connector

2×N (N≥2) PLC Splitter (with Connector) Optical Parameter

Parameter

2X2

2x4

2x8

2x16

2x32

2x64

Wavelength (nm)

1260 ～ 1650

IL (dB)

≤4.4

≤7.7

≤10.8

≤14.1

≤17.4

≤20.7

Uniformity (dB)

≤0.6

≤0.7

≤0.8

≤1.2

≤1.5

≤2.0

RL (dB)

≥50(PC), ≥55(APC)

PDL (dB)

≤0.2

≤0.3

≤0.4

Directivity (dB)

≥55

Environment

Operating Temp. (℃)

-40~85℃

Storage Temp. (℃)

-40~85℃

Humidity

≤95% (+40℃)

Atmospheric Pressure

62~106kPa

Fiber

SM G657A or customized

Connector

SC, FC, LC

Pigtail (mm)

1000, 1500, 2000 or customized

Remark:
(1) Test in room temperature and include connector.
(2) R≥55dB without connector

Size	nx2	nx4	nx8	nx16	nx32 (SX)	nx32 (HX)	nx64 (SX)	nx64 (HX)
L x W x D	130x100x25					130x100x50	130x100x102	266x100x50	130x100x206	266x100x100
