Product Details
Place of Origin: Zhejiang, China
Brand Name: DOWELL
Model Number: DW-OFI
Payment & Shipping Terms
Price: $99.00 - $119.00/pieces
Type: |
Fiber Identifier |
Use: |
FTTH |
Warranty Time: |
1Year |
Network: |
FTTH |
Identified Wavelength Range: |
800-1700 Nm |
Signal Direction: |
Left & Right LED |
Detector Type: |
1mm InGaAs 2pcs |
Type: |
Fiber Identifier |
Use: |
FTTH |
Warranty Time: |
1Year |
Network: |
FTTH |
Identified Wavelength Range: |
800-1700 Nm |
Signal Direction: |
Left & Right LED |
Detector Type: |
1mm InGaAs 2pcs |
Identified Wavelength Range | 800-1700 nm | ||
Identified Signal Type | CW, 270Hz±5%，1kHz±5%，2kHz±5% | ||
Detector Type | Ø1mm InGaAs 2pcs | ||
Adapter Type | Ø0.25 (Applicable for Bare Fiber)，Ø0.9 (Applicable for Ø0.9 Cable ) | ||
Ø2.0 (Applicable for Ø2.0 Cable ), Ø3.0 (Applicable for Ø3.0 Cable ) | |||
Signal Direction | Left & Right LED | ||
Singe Direction Test Range (dBm, CW/0.9mm bare fiber) | -46~10(1310nm) | ||
-50~10(1550nm) | |||
Signal Power Test Range (dBm, CW/0.9mm bare fiber) | -50~+10 | ||
Signal Frequency Display (Hz) | 270, 1k, 2k | ||
Frequency Test Range | Ø0.9, Ø2.0, Ø3.0 | -30~0 (270Hz,1KHz) | |
-25~0 (2KHz) | |||
Ø0.25 | -25~0 (270Hz,1KHz) | ||
-20~0 (2KHz) | |||
Insertion Loss(dB, Typical Value) | 0.8 (1310nm) | ||
2.5 (1550nm) | |||
Alkaline Battery(V) | 9 | ||
Operating Temperature(℃) | -10－+60 | ||
Storage Temperature(℃) | -25－+70 | ||
Dimension (mm) | 196x30.5x27 | ||
Weight (g) | 200 | ||
