PC ABS Fiber Optic Splice Closure Wall Mounting With 6 Ports

Large Image : PC ABS Fiber Optic Splice Closure Wall Mounting With 6 Ports

Product Details:

Place of Origin:	Zhejiang, China
Brand Name:	DOWELL
Model Number:	FOSC-H3B

Payment & Shipping Terms:

Minimum Order Quantity:	100 pieces
Delivery Time:	7-15 Days
Payment Terms:	T/T, Western Union, Paypal
Supply Ability:	1000 PCS Per 7 Days

Contact Now

PC ABS Fiber Optic Splice Closure Wall Mounting With 6 Ports

Description

Type:

Inline Type

Splice Tray:

4pcs

Material:

PC PC/ABS

Number Of Inlet/Outlet Ports:

6 Ports

Highlight:

6 Ports Fiber Optic Splice Closure

ABS Fiber Optic Splice Closure

ABS dome splice closure

FTTB Inline Type Optical Fiber Closure PC Or ABS 96 Fibers Wall-mounting

Fiber Optic Splice Closures is used for protective connection of two or multiple optical cable and optic fiber distribution .It is one of commonly used equipment of user access point .Used for the outdoor connection between optical distribution cable and optical in-room cable.Available for aerial,duct,direct buried application. High quality PC, ABS, PPR material optional, can ensure harsh conditions such as vibration, impact, tensile cable distortion and strong temperature changes.

Specification

Type	Inline type
Number of Inlet/Outlet ports	6 ports
Cable Diameter	2 ports×13mm, 2 ports×16mm, 2 ports×20mm
Maximum Capacity	Bunchy: 96 fibers
Capacity per Splice Tray	Bunchy: single layer: 12 fibers; dual layers: 24 fibers; Ribbon: 6pcs
Quantity of Splice Tray	4pcs
Body Material	PC PC/ABS
Sealing Material	Thermoplastic rubber
Assembling method	Aerial, direct buried, pipelined, wall mounting, manhole
Dimension	470(L)×185(W)×125(H)mm
Net Weight	2.3-3.0KG

Applications

Commonly used in telecommunications, CATV networks, and enterprise networks.

Ideal for fiber-to-the-home (FTTH), fiber-to-the-building (FTTB), and other fiber optic deployment scenarios.

Advantages of Horizontal Splice Closures

1. Ease of Access: The horizontal design allows for easy cable entry and exit, simplifying installation and maintenance.
2. Versatility: Suitable for a wide range of fiber counts and installation environments.
3. Protection: Provides excellent protection for spliced fibers, ensuring long-term reliability.
4. Scalability: Modular designs allow for future expansion or upgrades.
