Mechanical Seal Fiber Optic Splice Closure 1 In 3 Out 48Fo For Long Haul Networks

Mechanical Seal Fiber Optic Splice Closure 1 In 3 Out 48Fo For Long Haul Networks
Mechanical Seal Fiber Optic Splice Closure 1 In 3 Out 48Fo For Long Haul Networks
Mechanical Seal Fiber Optic Splice Closure 1 In 3 Out 48Fo For Long Haul Networks Mechanical Seal Fiber Optic Splice Closure 1 In 3 Out 48Fo For Long Haul Networks Mechanical Seal Fiber Optic Splice Closure 1 In 3 Out 48Fo For Long Haul Networks Mechanical Seal Fiber Optic Splice Closure 1 In 3 Out 48Fo For Long Haul Networks Mechanical Seal Fiber Optic Splice Closure 1 In 3 Out 48Fo For Long Haul Networks

Large Image :  Mechanical Seal Fiber Optic Splice Closure 1 In 3 Out 48Fo For Long Haul Networks

Product Details:
Place of Origin: Zhejiang, China
Brand Name: DOWELL
Model Number: FOSC-D3-M
Payment & Shipping Terms:
Minimum Order Quantity: 200pieces
Delivery Time: 7-15 Days
Payment Terms: T/T, Western Union, Paypal
Supply Ability: 1000 PCS Per 7 Days
Contact Now

Mechanical Seal Fiber Optic Splice Closure 1 In 3 Out 48Fo For Long Haul Networks

Description
Material: ABS+PP, PC ABS, Plastic+Metal Color: Black, OEM
Splice Capacity: 48 FO Cable Ports: 4
Splice Tray Capacity: 6/12 FO NO. Of The Splice TraY: 4pcs
Highlight:

Mechanical Seal Fiber Optic Splice Closure

,

Mechanical Seal fusion splice enclosure

,

48Fo Fiber Optic Splice Closure

Mechanical Seal FOSC Fiber Dome Enclosure 1 In 3 Out 48Fo For Long-Haul Networks

Fibre optic Mechanical Seal Vertical splice closures are an excellent protector of fibre optic joints from the outdoor environment such as UV, water, and weather with leakproof sealing having IP 68 protection. For easy splicing operation, closure consists of a well-managed no. of cable through and splice tray. Suitable for aerial, cable duct, direct buried, pedestal and provides the perfect solutions for the protection of fiber splice points from the environment. Suitable for multi-customer cables export, give a better solution for FTTH project.

Specification:

Dimensions (mm) 288×Ø 180 Material Modified polycarbonate
Numbers of Cable ports 4 Life expectancy 20 years
Cable diameter (Max.) Ø 13mm UV resistant additives 5%
Splice tray capacity 6/12 FO Flame resistant V1
Maximum numbers of the splice tray 4pcs Seal material of the box Rubber
Splice capacity in total 48 FO Seal material of the ports Rubber
Mounted way aerial, wall, pole, underground, manhole Protection rating IP68
Features & Benefits:
① High quality engineering plastic, long service life
② Reliable gasket sealing system, rated to IP68
③ High compressive strength.
④ Multi-cables are allowed to pass through a same port with mechanical lock.
⑤ Suitable for aerial, wall, manhole and pole mounted.
Application:

1. Telecommunications: Protecting fiber splices in FTTH (Fiber-to-the-Home), FTTB (Fiber-to-the-Building)

2. long-haul networks.

3. Aerial Installations: Mounted on poles or towers for overhead fiber networks.

4. Underground Installations: Buried underground to protect fiber splices in buried cable systems.

5. Direct Burial: Installed directly in the ground for rural or remote network deployments.

6. Industrial Environments: Used in harsh conditions where robust protection is required.

Mechanical Seal Fiber Optic Splice Closure 1 In 3 Out 48Fo For Long Haul Networks 0

More Details Show:

Mechanical Seal Fiber Optic Splice Closure 1 In 3 Out 48Fo For Long Haul Networks 1Mechanical Seal Fiber Optic Splice Closure 1 In 3 Out 48Fo For Long Haul Networks 2

Mounted way:



Mechanical Seal Fiber Optic Splice Closure 1 In 3 Out 48Fo For Long Haul Networks 3
