|Insertion Loss:||≤0.2dB||Return Loss:||≥50dB|
SC APC Fiber Optic Adapter Simplex Duplex and SM MM
1. Connector Type: SC adapter, RoHS compliant , 100% Optical Test
2. S: Simplex D:Duplex
3. SM: single mode MM: multi-mode
4. Structure:Square Separate/Square Seamless/D type
5. Sleeve: Zirconia, Bronze
6. Polishing Grade: PC(SM with blue color), APC(SM with green color,MM with beige)
7. Fiber type: SM(9/125㎛), MM(62.5/125㎛).
SC the structure of pin and plastic housing is same with FC, the fastening mean is plug-in latch, no need to revolve. The advantage for ST connector is low cost, easy operation with small insertion lost and high compressive strength.ST With fastening mean is plug-in type ,the core of ST is outside while the core of SC is inside. For connection of 10Base-F is usually with ST but for 100Base-FX is usually with SC.
LC With RJ module function for easy operation, the size is a half of SC type.
Optic flange adapter coupler SC type simplex duplex APC UPC fiber optic adapter
Accord with the standard of ANSL,Bellcore,TIA/EIA,IEC
With high precise dimension
Ceramic or bronze house
Low insertion(<0.2dB),hign return loss(≥50dB)
Changebility is more than one thousand,repeatibility is less than 0.2dB
1.the inner packing is plastic bag
2.the outer packing is carton
|SC FIBER OPTIC ADAPTER|
|Insertion loss||dB||≤ 0.2|
|Return loss||dB||PC≥45 UPC≥50 APC≥60|
|Mechanical endutance(500T)||dB||≤ 0.2|
|Attenuation value||dB||+/- 0.5(≤10 dB)||0~3|
|+/-1.0 (>10 dB)|
|Max. Optic input power||mW||500||500|
Fiber Optic FC Adapter
Yuhui has a complete series of fiber optics interconnect products include pigtail,adapter,patch cords, using for CATV,telecommunication networks,test equipment,metro and local area networks. Optical fiber pigtail is something like a half patch cord to make connection between optical fiber and fiber adapters or connection between transmission equipments and ODF.
The pigtail with one active optical adapter while the patch cord with two active connectors. There are many different interfaces which require different adapters.They all with low insertion loss and back reflection loss.Production under
FC (short for Ferrule connector), with a metal sleeve to strengthen its external side, the fastening mean is turnbuckle. The advantage for FC connector is easy function, operation and manufacture. Mainly used on patch panels.
MT-RJ Its latch-up structure is same with RJ-45 type Lan connectors. In order to connect to the optical transceiver facilitate, the end face is desired as double core optical fiber.
Fast Ethernet,Data Communication LAN and WAN
High speed Enterprise servers
Multiplexers,switches and routers
Optical Access and ATM Networks Equipment
Optical Transport and Telecommunications,FTTH,FTTD,FTTX
|Insertion Loss||≤0.2 dB||≤0.2 dB||≤0.3dB|
|Plug and unplug force(g/f)||200-600|
|Durability plug and unplug||1000times|
|Operation Tempreture||-40℃ to +75℃|
|Material||ABS/PBT,Ceramic (Zirconia),Phosphor Bronze alignment sleeves|
Hot and new designed with more advantage adapters and connectors,please check with CONTACT !
We make sure that every product is 100% tested in the factory before packing.
Our products are popular with world's Telecom operator and users.Clients from America, South America, Europe,Asia and Africa and happy with our quality.We can offer OEM and ODM service according to customer's requirement as well. Better quality leads to more success ! One hundred successful orders lost in a complaint !
Order to be delivered goods within 7-10 days after we received your payment usually.For exact date,please check with our sales. Meanwhile,we could provide competitive shipping service for you, by sea, by air or by express. Appointed forwarder is also available as you prefer.
