Telecom Cable Installation Galvanized 6mm Fiber Cable Clamp with Six Way Double Holes

Large Image : Telecom Cable Installation Galvanized 6mm Fiber Cable Clamp with Six Way Double Holes

Product Details:

Place of Origin:	Zhejiang, China
Brand Name:	Dowell
Model Number:	DW-1071- Feeder Clamps

Payment & Shipping Terms:

Price:	$1.69/pieces 1-1999 pieces
Packaging Details:	Normal Package
Supply Ability:	30000 Piece/Pieces per Week

Contact Now

Telecom Cable Installation Galvanized 6mm Fiber Cable Clamp with Six Way Double Holes

Description

Type:	Feeder Clamp	Use:	Feeder Cable Clamp
Network:	Wired LAN, FTTH	Product Name:	Fiber Optic Cable Suspension Clamp
Application:	Telecom Cable Installation	Usage:	Electric Power Accessories
Operation Temp:	-50 °C ~ 85 °C	Warranty:	1 Year
Color:	Black	Material:	304 Stainless Steel
Certificate:	CE ROHS ISO9001	Cable Capacity:	2,4,6,8,10,12 Etc
Size:	Customize Accept	Port:	Ningbo

One Hole Per Layer

Two Same Holes Per Layer

Two Different Holes Per Layer

More options you could pick

Every Layer could be combined according customer‘s need.

Suitable Cables	D1---Power Cable
Cable Size	9-13mm
Suitable Cables	D2---Fiber Cable
Cable Size	4.5-7mm
Layers Quantity	Could be customized

This cable clamp is a sort of module assembly for fixing cables. It' s made of resist ultraviolet and enduring high temperature material. It fits for fixing the circular fiber cable of φ7mm orφ7.5mm and 3.3 square, 4 square, 6 square, 8.3 square cable. It can set three fiber cables and three cables in most. The C-shape bracket is light and terse and It' s easy to fix reliably.

Besides, it can offer a combined solution for power cables (DC) and fiber optic cables (FO). This clamp is very effective and flexible when fixing different size of DC power cables.

Clamp type	European standard	Cable Type	Power (hybrid) cable and fiber cable
Size	OD 12-22mm DC power cable OD 7-8mm fiber cable	Number of Cables	3 power cable + 3 fiber cable
Operation Temp	-50 °C ~ 85 °C	UV Resistance	≥1000 hours
CompatibleMax Diameter	19-25mm	Compatible Min Diameter	5-7mm
Twin Plastic Clamps Material	Fiberglass reinforced PP,Black	Metal Material	Stainless steel 304 or hot galvanized
Mounting On	Steel wire cable tray	Max Stack Height	3
Vibration Survival	≥4 hours at resonant frequency	Environmental Strength Cap	Double cable weight

This Fiber Optic Cable Clamp is widely used for :
* Telecom cable
* Fiber cable
* Coaxial cable
* Feeder cable
* Hybrid cable
* Corrugated cable
* Smooth cable
* Braid cable

1. Disentwine the special bolt of the C-bracket till the ringent distance is bigger than the thick of one
side of angle iron. And then tighten the special bolt M8; (Reference torque: 15Nm)
2. Please retire the nut onto the threaded rod ,and unclench the plastic clip;
3. Disjoin the plastic clamp,plunge the Fiber cable ofφ7mm orφ7.5mm into the small hole of plastic
clamp, plunge the 3.3 square or 4 square cable into the hole of the black rubber pipe in plastic clamp.
Remove the rubber pipe from the plastic clamp for the 6 square or 8.3 square cable and plunge the
cable into the hole of plastic clamp (figure right);
4. Lock all nuts at last. (Reference torque of lock nut M8 for clamp: 11Nm)
