2.0*3.0mm Cable Diameter SC/APC to SC/UPC Fiber Optic Patch Cord for FTTx CATV Network

2.0*3.0mm Cable Diameter SC/APC to SC/UPC Fiber Optic Patch Cord for FTTx CATV Network
2.0*3.0mm Cable Diameter SC/APC to SC/UPC Fiber Optic Patch Cord for FTTx CATV Network 2.0*3.0mm Cable Diameter SC/APC to SC/UPC Fiber Optic Patch Cord for FTTx CATV Network 2.0*3.0mm Cable Diameter SC/APC to SC/UPC Fiber Optic Patch Cord for FTTx CATV Network 2.0*3.0mm Cable Diameter SC/APC to SC/UPC Fiber Optic Patch Cord for FTTx CATV Network 2.0*3.0mm Cable Diameter SC/APC to SC/UPC Fiber Optic Patch Cord for FTTx CATV Network 2.0*3.0mm Cable Diameter SC/APC to SC/UPC Fiber Optic Patch Cord for FTTx CATV Network

Large Image :  2.0*3.0mm Cable Diameter SC/APC to SC/UPC Fiber Optic Patch Cord for FTTx CATV Network

Product Details:
Place of Origin: Zhejiang, China
Brand Name: DOWELL
Model Number: DW-PSA-M
Payment & Shipping Terms:
Price: $48.00/pieces 1-4999 pieces
Packaging Details: Normal Package
Supply Ability: 30000 Piece/Pieces per Week

2.0*3.0mm Cable Diameter SC/APC to SC/UPC Fiber Optic Patch Cord for FTTx CATV Network

Description
Type: Fiber Optic Patch Cord Use: FTTP,CATV
Network: Wired LAN Material: RoHS And REACH Materials Compliant.
Cable Diameter Range:: 2.0*3.0mm, 2.0*5.0mm, 3.0mm. Mechanical Performance:: IEC 61754-4 Standard
Warranty: 1 Year No. Of Fiber: 1.
Port: Ningbo

2.0*3.0mm Cable Diameter SC/APC to SC/UPC Fiber Optic Patch Cord for FTTx CATV Network 0
2.0*3.0mm Cable Diameter SC/APC to SC/UPC Fiber Optic Patch Cord for FTTx CATV Network 1
● Cost effective solution for in house termination.
● Low insertion loss and added loss.
● Height of attenuation.
● IP67 water, dust proof and corrosion resistant
● The material in the jumpel cable are all-weather and UV-resistant.
● Mechanical performance: IEC 61754-4 standard.
● RoHS and REACH materials compliant.
● Cable diameter Range: 2.0*3.0mm, 2.0*5.0mm, 3.0mm.

Dimensional Diagrams

1. IPSC/APC 3.0mm Cable Assemblies.
2.0*3.0mm Cable Diameter SC/APC to SC/UPC Fiber Optic Patch Cord for FTTx CATV Network 2

2. IPSC/APC 2.0*3.0mm Cable Assemblies
2.0*3.0mm Cable Diameter SC/APC to SC/UPC Fiber Optic Patch Cord for FTTx CATV Network 3
3. IPSC/APC 2.0*5.0mm Cable Assemblies
2.0*3.0mm Cable Diameter SC/APC to SC/UPC Fiber Optic Patch Cord for FTTx CATV Network 4
Overall Length (L, m)
length of tolerance (cm)
0<L≤20
+10/-0
20<L≤40
+15/-0
L>40
+0.5%L/-0
Cable Structure
2.0*3.0mm Cable Diameter SC/APC to SC/UPC Fiber Optic Patch Cord for FTTx CATV Network 5
Cable Parameters
Cable
Count
(F)
Out Sheath
Diameter
(MM)
Weight
(KG)
Minimum Allowable
Tensile Strength
(N)
Minimum Allowable
Crush Load
(N/100mm)
Minimum Bending
Radius
(MM)
Storage
Temperature
(℃)
Short Term
Long Term
Short Term
Long Term
Short Term
Long Term
1
(2.0±0.1) x (3.0±0.2)
8
100
50
500
100
20D
10D
-20 ~ +60
Cable Structure
2.0*3.0mm Cable Diameter SC/APC to SC/UPC Fiber Optic Patch Cord for FTTx CATV Network 6
Cable Parameters
Cable
Count
(F)
Out Sheath
Diameter
(MM)
Weight
(KG)
Minimum Allowable
Tensile Strength
(N)
Minimum Allowable
Crush Load
(N/100mm)
Minimum Bending
Radius
(MM)
Storage
Temperature
(℃)
Short Term
Long Term
Short Term
Long Term
Short Term
Long Term
1
3.0±0.15
6.5
150
80
500
100
20D
10D
-20 ~ +60
2.0*3.0mm Cable Diameter SC/APC to SC/UPC Fiber Optic Patch Cord for FTTx CATV Network 7
2.0*3.0mm Cable Diameter SC/APC to SC/UPC Fiber Optic Patch Cord for FTTx CATV Network 8
2.0*3.0mm Cable Diameter SC/APC to SC/UPC Fiber Optic Patch Cord for FTTx CATV Network 9
2.0*3.0mm Cable Diameter SC/APC to SC/UPC Fiber Optic Patch Cord for FTTx CATV Network 10
2.0*3.0mm Cable Diameter SC/APC to SC/UPC Fiber Optic Patch Cord for FTTx CATV Network 11
2.0*3.0mm Cable Diameter SC/APC to SC/UPC Fiber Optic Patch Cord for FTTx CATV Network 12
2.0*3.0mm Cable Diameter SC/APC to SC/UPC Fiber Optic Patch Cord for FTTx CATV Network 13
2.0*3.0mm Cable Diameter SC/APC to SC/UPC Fiber Optic Patch Cord for FTTx CATV Network 14
2.0*3.0mm Cable Diameter SC/APC to SC/UPC Fiber Optic Patch Cord for FTTx CATV Network 15
● Permanent termination of optical fiber via fusion splicing
● Permanent termination of optical fiber via mechanical splicing
● Temporary termination of optical fiber cable for acceptance testing
2.0*3.0mm Cable Diameter SC/APC to SC/UPC Fiber Optic Patch Cord for FTTx CATV Network 16
2.0*3.0mm Cable Diameter SC/APC to SC/UPC Fiber Optic Patch Cord for FTTx CATV Network 17
2.0*3.0mm Cable Diameter SC/APC to SC/UPC Fiber Optic Patch Cord for FTTx CATV Network 18
2.0*3.0mm Cable Diameter SC/APC to SC/UPC Fiber Optic Patch Cord for FTTx CATV Network 19
2.0*3.0mm Cable Diameter SC/APC to SC/UPC Fiber Optic Patch Cord for FTTx CATV Network 20
2.0*3.0mm Cable Diameter SC/APC to SC/UPC Fiber Optic Patch Cord for FTTx CATV Network 21
2.0*3.0mm Cable Diameter SC/APC to SC/UPC Fiber Optic Patch Cord for FTTx CATV Network 22
2.0*3.0mm Cable Diameter SC/APC to SC/UPC Fiber Optic Patch Cord for FTTx CATV Network 23
1. Q : Are you trading company or manufacturer?
A : 70% of our products we manufactured and 30% do trading for customer service
2. Q : How can you ensure the quality?
A : Good question! We are a one-stop manufacturer. We have complete facilities and over-15- years manufacturing experience to ensure product quality. And we have already passed ISO 9001 Quality Management System.
3. Q : Can you provide samples ? Is it free or extra?
A : Yes, After price confirmation , we could offer the free sample, but the shipping cost need pay for by your side.
4. Q : How long is your delivery time ?
A : In stock: In 7 days; No in stock: 15~20 days, depend on your QTY.
5. Q: Can you do OEM?
A: Yes , we can
6. Q: What is your payment term ?
A: Payment <=4000USD,100% in advance. Payment>= 4000USD, 30% TT in advance, balance before shipment.
7. Q: How we can pay?
A: TT, Western Union , Paypal ,Credit Card and LC
8. Q: Transportation?
A: Transported by DHL, UPS, EMS, Fedex, Air freight, Boat and Train
