Product Details:
|
| Fiber Type: | G652D / G657A | No. Of Fiber: | 1-4F |
|---|---|---|---|
| Self-Support Material: | Steel Strand Wire | Strength Member Material: | FRP/KFRP |
Self-supporting FRP KFRP Optic Drop Cable For FTTH Outdoor 2*5.0mm G652D G657A
FTTH Drop cables connect the main distribution cable traversing a region to end-user homes or commercial buildings. These cables bridge the fi nal stretch from the fiber backbone to the premises – often called fi ber to the home (FTTH).
Technical Parameters
| Fiber Count | Cable Diameter mm |
Cable Weight Kg/km |
Tensile Strength Long/Short Term N |
Crush Resistance Long/Short Term N/100m |
Bending Radius Static/Dynamic mm |
| 1 | (2.0±0.2)×(5.0±0.2) | 8.8 | 600/1000 | 1000/2200 | 20D/40D |
| 2 | (2.0±0.2)×(5.0±0.2) | 8.8 | 600/1000 | 1000/2200 | 20D/40D |
| 4 | (2.0±0.2)×(5.0±0.2) | 8.8 | 600/1000 | 1000/2200 | 20D/40D |
| 6 | (2.0±0.2)×(5.0±0.2) | 9.2 | 600/1000 | 1000/2200 | 20D/40D |
| G.652 | G.657 | 50/125um | 62.5/125um | ||
| Attenuation (+20 ) |
@850nm | ≤3.5 dB/km | ≤3.5 dB/km | ||
| @1300nm | ≤1.5 dB/km | ≤1.5 dB/km | |||
| @1310nm | ≤0.35 dB/km | ≤0.25 dB/km | |||
| @1550nm | ≤0.30 dB/km | ≤0.22 dB/km | |||
| Bandwidth | @850nm | ≥500 Mhz.km | ≥200 Mhz.km | ||
| Class A 850nm | @1300nm | ≥1000 Mhz.km | ≥500 Mhz.km | ||
| Numerical aperture | 0.200±0.015NA | 0.275±0.015NA | |||
| Cable Cutoff Wavelength | ≤1260nm | ≤1480nm | |||
| No. of Fiber | 1-4F | |||
| Gross weight | 18.0kg/km | |||
| SM Fiber | Fiber Type | G652D/ G657A | MFD | 8.8 ~ 10.5um |
| Cladding diameter | 125±0.7um | Cladding non-circularity | ≤1.0% | |
| Coating diameter | 242±7um | Fiber color | standard spectrum | |
| Strength member | Material | FRP/KFRP | Color | white |
| Diameter | 0.5mm | Qty | 2 | |
| Self-Support | Material | Steel strand wire | ||
| Diameter | 0.4×7-1.2 | |||
| Out sheath | Material | LSZH | Color | Black |
| Diameter | (2.0±0.2) × (5.0±0.2) | Thickness | ≧0.5mm | |
Application
It ideal for high-speed internet access, interactive digital services, voice services, LANs, security systems, industrial automation systems, and telecommunications networks.
