|Product Name:||Fiber Optic Distribution Termination Box||Material:||PC+ABS|
|Cable:||Splitter||Capacity:||16 And 24cores Types|
optical termination box,
fiber optic junction box
Fiber Optic FTTH Box Fiber Optic Termination Box 16core Fiber Splitter terminal Box
1. Strengthen Polymer Plastic material used ensures the body strong and light.
2. Water-proof design for outdoor uses,Resistance and dustproof,flame-retardant.
3. Space saving! Splitter for easier installation and maintenances,extra fiber cable storage.
4. Adapter Capacity: 1*16 PLC splitter,3*8 PLC splitter
This is a fiber access termination closure which is able to hold up to 16-24 subscribers and 96 splicing points as closure. It is used as a splicing closure and a termination point for the feeder cable to connect with drop cable inFTTx network system. It integrates fiber splicing, splitting, distribution, storage and cable connection in one solid protection box.Supports 2 configurations: up to 2 splicing trays with up to 16 fusions each, plus an adapter tray with up to 16 positions and storage of up to two splitters;It also provides management and storage of optical adapters for connectorized outputs. It has a mechanical seal system.This Optical Termination Closure is designed to seal with screws and buckles.The compact size and flip-over cover bring easy operation as well as complete function.The splice trays are jointed with a hinge at one side, which makes the operation in each tray easier.
Water-proof design with IP-68 Protection level.
Integrated with flap-up splice cassette and adaptor holder.
Impact test:IK10,Pull Force:100N,Full rugged design
All stainless metal plate and anti-rusting bolts,nuts.
Fiber bend radius control more than 40mm.
2 pcs of 1*8 Splitter can be installed as an option.
Mechanical sealing structure and mid-span cable entry.
16 ports cable entrance for drop cable.
24 adaptors for drop cable patching
Wall mounting and pole mounting installtion
FTTH pre-installation and filed installation
4-7mm cable ports suitable for 2x3mm indoor FTTH drop cable and outdoor figure 8 FTTH self-supporting drop cable
Splice cassette and cable management tool, installation nuts and bolts, protection sleeves, hose clamp, cable tube, wreach, cover holder, rubber seal for cable entrance.
The Fiber optic distribution termination box offered mainly for below feature:Material: PC+ABS, wet-proof,water-proof,dust-proof,anti-aging, protection level up to IP65;Clamping for feeder cable and drop cable, fiber splicing, fixation, storage, distribution…etc all in one
Cable, pigtails , patch cords are running through own path without disturbing each other, cassette type SC/LC/PLC adaptor installation, easy maintenance.Distribution panel can be flipped up, feeder cable can be placed in a cup-joint way, easy for maintenance and installation.
Cabinet can be installed by the way of wall-mounted, suitable for both indoor and outdoor uses.
Relative humidity: ≤85%(+30C)
Atmospheric pressure: 70KPa～106 KPa
2. Optical Performance
Insertion loss: ≤0.2dB
UPC return loss≥50 dB
APC return loss≥60 dB
Life of insertion and extraction: >1000 times
The grounding device is isolated with the cabinet, isolation resistance is less than 2x104MΩ/500V(DC); IR≥2x104MΩ/500V
The withstand voltage between grounding device and cabinet is no less than 3000V(DC)/min, no puncture, no flashover; U≥3000V
We offer Fiber fast connector,fast connector fiber optic,fast connector SC,lc fast connector,ftth fast connector.Fiber quick connector with good quality,fiber optic quick connector for FTTH project.Good performance of fiber optic adapter,fiber adapter,LC adapter,SC adapter with shutter,fiber coupler,lc coupler multimode,lc duplex adapter,optical adapter,optical cable adapter,fiber connector,fiber optic connectors,sc connector,fiber connector types,lc fiber connector,fiber optic cable connectors.Fiber termination with fiber accessories including lc duplex connector,fast connector,patch cord types,fiber patch cord,fiber optic patch cord,fiber optic patch cable,fiber jumper,fiber optic patch cord supplier,duplex patch cord,simplex patch cord,single mode fiber patch cord,patch cord manufacturer,SC patch cord,fiber pigtail,fiber optic pigtail,pigtail lc,pigtail sc,optical pigtail,pigtail st,fiber optic pigtail connector,pigtail multimode,lc apc pigtail,sc pigtail single mode,upc connector,SC ST connector,fiber socket,fiber optic socket,fiber optic pigtail connector,fc patch cord,patch cord connector,loose tube fiber termination,bare fiber connector,single mode fiber termination.
Fiber termination box,fiber optic termination box,ftth box,fiber distribution box,fiber optic junction box,juint box fiber optic,optical termination box,outdoor fiber termination box,odf box,optical fiber distribution box,fiber termination box wall mount,fiber joint box,fiber junction box,ftth fiber optic termination box,fiber termination box price,odf fiber box,underground fiber optic junction box,indoor fiber termination box,fiber optic enclosure box,fiber management box,fiber optic cable junction box,rack mount fiber termination box.Fiber Optic Terminal Distribution Box,Optical termination box,Fiber termination box wall mount,Outdoor fiber distribution box,Indoor optical terminal box,Ftth fiber optic termination box,Fiber connect socket,Fiber optic jumper fiber optic patch cord,Fiber optic assembly,Fiber fast connector,Fast connector fiber optic,LC fast connector,Fast connector LC,Ftth fast connector,Field installable fiber optic connector,Fast SC connector,Quick connector.
The FTTH Installation Accessories Set concludes:junction box,fiber wall socket(also named Single family unit rosette,SFU rosette),draw hooks,cable clamp,cable wall bushings,cable glands,cable clips,tail duct,cable wiring duct,nail clip.
Cable bushings were originally designed for indoor use on sheet rock.Cable bushings are plastic grommets inserted into a wall to provide a clean appearance for coax cable,fiber optic cable and all cable entry. Cable bushings are a low cost and fast alternative to installing traditional wall plates.They protect the cable from sharp edges when in applications. We offer different shape and size cable wall bushings,wall tubes,fiber inside corner,fiber outside corner,flat elbow,raceway duct fitting,raceway molding,bend radius,tail duct,cable clamp,wiring duct.All used for fiber optic cabling and other wire cabling projects.
Fiber Optic Exterior Slack Storage W/O Holes hidden and organized.Slack storage box is used for exterior slack storage applications using single fiber cable. There are two stackable storage spools that allow storage of multiple single fiber cable drops. Both of these spools are removable. In an instance where only one spool is sufficient, the spool can either be secured at a lower level or can be mounted at an elevation onto the risers off the back of the inside of the box as a spool on the upper level. This allows additional storage under the spool.
Fiber Inside Corner, Inside corner for the self adhesive single fiber molding.
Fiber Flat Elbow, Flat elbow for the self adhesive single fiber molding.
Fiber Outside Corner,Outside corners for the self adhesive single fiber molding.
|Material||Cold rolled steel for the box, ABS for the tray|
|Capacity||12core (12core,24core,48core,72core,96core,144core is available)|
|Installation Method (in overstriking )||Floor Standing / wall mounted / pole mounted / rack mounted / corridor mounted / mounted in cabinet|
