SC APC Simplex Fiber Optic Adapter With Shutter For ODF Telecom RoHS

SC APC Simplex Fiber Optic Adapter With Shutter For ODF Telecom RoHS

    • SC APC Simplex Fiber Optic Adapter With Shutter For ODF Telecom RoHS
    • SC APC Simplex Fiber Optic Adapter With Shutter For ODF Telecom RoHS
  • SC APC Simplex Fiber Optic Adapter With Shutter For ODF Telecom RoHS

    Product Details:

    Place of Origin: China
    Brand Name: YUHUI
    Certification: ISO,RHOS,UL,CE
    Model Number: YH-FO-SC-A

    Payment & Shipping Terms:

    Minimum Order Quantity: 5000pieces
    Price: Negotiation
    Packaging Details: 5000piece/box
    Delivery Time: 7days
    Payment Terms: TT,LC,West Union
    Supply Ability: 5000000pieces/month
    Contact Now
    Detailed Product Description
    Module: SC/APC Adapter Material: Fire Resist Plastic
    Color: Green Dust Shutter: Selection Of Various Dust Caps
    Certification: Rohs,SGS,CE Sleeve: Precision Ceramic Sleeve And Ferrule

    SC APC Simplex Adapter Fiber Optic Adapter With Shutter For ODF Telecom RoHS


    Quick Detail:


    1. Connector Type: SC/APC adapter, RoHS compliant , 100% Optical Test

    2. S: Simplex D:Duplex

    3. SM: single mode MM: multi-mode

    4. Structure:Square Separate/Square Seamless/D type

    5. Sleeve: Zirconia, Bronze

    6. Polishing Grade: PC(SM with blue color), APC(SM with green color,MM with beige)

    7. Fiber type: SM(9/125㎛), MM(62.5/125㎛).

    8. Excellent Temperature stability,Low insertion loss ,high return loss
    9. Excellent mechanical endurance,Compliant with Telcordia,TIA/EIA and IEC




    The optical fiber is connected by an adapter through its internal open precision ceramic sleeve. We provide a variety of high-performance adapters in various shapes to ensure accurate connection between fiber optic active connectors. In order to fix on various boards and use in different environments, our company provides a variety of exquisite fiber adapters such as: Simplex Shuttered Adapter Without Flange, Simplex Shuttered Adapter, Outer Shutter Adapter Without Flange,Outer shutter adapter, one-piece fiber adapter, unibody fiber adapter etc.


    Material:Fire resist plastic

    Connector type: SC-SC

    Polish type:APC (UPC optional)

    Fiber Mode:Singlemode;Multimode;OM3;OM4;OM5

    Color: SM: BLue,Green;MM:Berge;OM3:Aqua;OM4:Violet;OM5:Lime green


    Flange:without flange/no ear



    Operating Tempreture:-40~70°C

    Durability:>1000 times

    Insertion loss:≤ 0.2db

    Module no.:SC SX One-Piece Adapter


    Packaging Details

    1.the inner packing is plastic bag
    2.the outer packing is carton


    Yuhui has a complete series of fiber optics interconnect products include pigtail,adapter,patch cords, using for CATV,telecommunication networks,test equipment,metro and local area networks. Optical fiber pigtail is something like a half patch cord to make connection between optical fiber and fiber adapters or connection between transmission equipments and ODF.



    CATV,Active device termination,telecommunication networks,metro,local area networks(LANs),data processing networks,test equipment,premise installations,wide area networks(WANs)


    Specifications :


    Type Singlemode/PC Singlemode/APC Multimode/PC
    Insertion Loss ≤0.2 dB ≤0.2 dB ≤0.3dB
    Plug and unplug force(g/f) 200-600
    Durability plug and unplug 1000times
    Operation Tempreture -40℃ to +75℃
    Material ABS/PBT,Ceramic (Zirconia),Phosphor Bronze alignment sleeves
