|For Drop Wire Connection:||Customer Wire (CW) And Drop Wire(DW) Connection||Plug:||Can Be For Protection Or Unprotection|
|Pair:||1Pair||Earthing:||With Or Without|
krone lsa plus module
Subscriber Drop Wire Connector With five-pole connection STB module Unprotected
1, Material: PBT or ABS(UL94V-0)
2, Contact: Phosphor Bronze
3, 5 pole connection
4, For Customer Wire (CW) and Drop Wire(DW) Connection
5, The plug can be with 3point protector(color red) and 5point protect (color orange),if without protection the color is grey
6. Available to install this drop wire module into 1pair distribution box,2pair distribution box,10pair distribution box ect.,waterproof,IP54.
7, 100% test passed,arrester voltage usually for 230V,it can be on your requirement.
1pair STB Module Without Protection Subscriber Connector Unit VX-SB
The STB module (1 pair drop wire connection module with protection ) provide a connection point between an exchange-side cable pair and a
distribution pair for telecommunication equipment. It incorporates a 5-point plug in module to provide continuity and a range of other options.
Removal of the plug-in module does not disturb wire connections but makes contacts to them available for testing of both sides of the telecommunication network.
The connection cables connection is carried out by displacement of isolate using a screwdriver with a width of 5-7 mm flat Screw on which it acts should be missed and will have a top clear of press to warn the operator that has made the connection.The connection on the network side will also be displacement of insulation without requiring the use of any special tools.The ducts where contacts are housed will be filled with a composite insulator which prevents the degradation of connection produced by the entry of dust and moisture. To make the connection just enter drivers in the accommodation which the connector has to do so and act on a screw that produces the inclusion in contacts without having to perform other concurrent operations.Housing utility cables possess a CAP to facilitate correct positioning of the same in order to facilitate the connection.The Multipair cable must supply connected. This connection will be protected by a protective insulating compound.The allowable diameter shall be:Network side: 0.4 to 0.8 mm, with a diameter of 1,5 mm. maximum insulation ;Client-side: 0.5-0.8 mm, with a maximum insulation diameter of 3.2 mm.
The STB module (1 pair drop wire connection module with protection ) is especially recommended for:
1. Outdoor connections where the environment conditions are extremely atrocious to protect telecommuniactin equipment and circuitry line.
2. Terminations where user development characteristics require future flexibility in terms of the type of protection or filtering capabilities. Offering box with capacity from 1pair to 20pair for application.
Item no. Description
YH-5027 Drop wire(STB) module without protection,Grey Plug
YH-5028 Drop wire(STB) module with GDT protection,Red Plug
YH-5029 Drop wire(STB) module with GDT and PTC protection,Orange Plug
The subscriber connector unit is used for the connection of an outdoor to an indoor drop wire. It allows for circuit testing in both network directions.The box provides environmental protection. The product is specially recommended for aggressive environmental conditions,terminations where future requirements
may include different types of protection.
|Mechanical Performance||Plastic material: ABS&PBT(UL94V-0)|
|Contact material: Phosphor Bronze.|
|Surface Plating Silver(0.5um-5um)|
|Earth bar: Phosphor Bronze.Surface Plating nickel|
|Environment Characteristic||Storage Tempreture: 40 to 70°C|
|Operating Temperature : 10 to 60°C|
|Relative Humidity: 95%, noncondition|
|Electrical Performance||Insulation resistance: 1000 Mohms minimum|
|Contact resistance :5 mohms maximum|
|Dielectric intensity: 1200V DC 60s can't spark over and haven't fly arc|
