Mini FTB Outdoor Fiber Optic Terminal Box IP65 Plastic FTTH Termination Box ODF Waterproof

China Mini FTB Outdoor Fiber Optic Terminal Box IP65 Plastic FTTH Termination Box ODF Waterproof supplier
Mini FTB Outdoor Fiber Optic Terminal Box IP65 Plastic FTTH Termination Box ODF Waterproof supplier Mini FTB Outdoor Fiber Optic Terminal Box IP65 Plastic FTTH Termination Box ODF Waterproof supplier Mini FTB Outdoor Fiber Optic Terminal Box IP65 Plastic FTTH Termination Box ODF Waterproof supplier Mini FTB Outdoor Fiber Optic Terminal Box IP65 Plastic FTTH Termination Box ODF Waterproof supplier Mini FTB Outdoor Fiber Optic Terminal Box IP65 Plastic FTTH Termination Box ODF Waterproof supplier

Large Image :  Mini FTB Outdoor Fiber Optic Terminal Box IP65 Plastic FTTH Termination Box ODF Waterproof

Product Details:

Place of Origin: China
Brand Name: YUHUI
Certification: ISO,RHOS,UL,CE
Model Number: YH-1068-8

Payment & Shipping Terms:

Minimum Order Quantity: 200pieces
Price: Negotiation
Packaging Details: 10piece/box
Delivery Time: 20days
Payment Terms: TT,LC,West Union
Supply Ability: 10000pieces/month
Contact Now
Detailed Product Description
Box Body Material: ABS New Material Protection Level: IP65.
Inside: Double-layer Design Application: For Cabling Outdoor Protection
Capacity: 4/6 SC/FC Simplex Adapters Or LC Duplex Installation: Wall Mounted Or Pole Mounted

6 Core Mini FTB Outdoor Fiber Optic Terminal box IP65 Plastic FTTH Box



Quick Detail:



1. ABS material used ensures the body strong and light.

2. Protection Level: IP65.

3. Water-proof design for outdoor uses, lock provided for extra security.resistance and dustproof,flame-retardant.

4. Space saving! Double-layer design for easier installation and maintenances

5. Dimensions: 210mm*140mm*40mm

6. Adapter Capacity 4/6 SC/FC simplex adapters or LC duplex adapters

7. Installation: Wall mounting or Pole mounting.



Description:



 Plastic FTTH Fiber Optic Termination Box 4cores,a newly developed box for application of FTTH,outdoor or indoor application. The box is with smaller size and light and compact, especially suitable for protective connection of fiber cables and pigtails in FTTH.IP class: IP65



Key option: plastic or metal

Mini FTB Outdoor Fiber Optic Terminal Box IP65 Plastic FTTH Termination Box ODF Waterproof

Specification:

Function:Cable termination,passive splitter

Splitter installation:Splitter fixing bracket

Adaptor type:SC simplex,LC duplex

Maximal capacity: 4 fibers indoor fiber cables

Cable inlet and outlet:1port to 4port

Lock function: lock with a plastic key,and two plastic sliplock, easy to operation.

Diemention:210mm*140mm*40mm (Two type capacity for this size:4cores and 6cores)

Installation: Wall mounting or Pole mounting.

Complied with Rohs





Applications:

  • FTTx, FTTH, FTTB, FTTO, Telecom network, CATV.Provide fusion and storage appliance for optical cables,for indoor fiber optic cable distribution.



Specifications :



Material Cold rolled steel for the box, ABS for the tray
Operating Temperature -40°C~+60°C
Relative Humidity <95%(+40°C)
Insulated resistance ≥2x10MΩ/500V(DC)
Capacity 4/6core (12core,24core,48core,72core,96core,144core is available)
Installation Method (in overstriking ) Floor Standing / wall mounted / pole mounted / rack mounted / corridor mounted / mounted in cabinet



The FTTH Installation Accessories Set concludes:junction box,fiber wall socket(also named Single family unit rosette,SFU rosette),draw hooks,cable clamp,cable wall bushings,cable glands,cable clips,tail duct,cable wiring duct,nail clip.

FTTH Cabling Indoor / Outdoor Assemble Fiber Optic AccessoriesFTTH Cabling Indoor / Outdoor Assemble Fiber Optic Accessories

Cable bushings were originally designed for indoor use on sheet rock.Cable bushings are plastic grommets inserted into a wall to provide a clean appearance for coax cable,fiber optic cable and all cable entry. Cable bushings are a low cost and fast alternative to installing traditional wall plates.They protect the cable from sharp edges when in applications. We offer different shape and size cable wall bushings,wall tubes,fiber inside corner,fiber outside corner,flat elbow,raceway duct fitting,raceway molding,bend radius,tail duct,cable clamp,wiring duct.All used for fiber optic cabling and other wire cabling projects.



Fiber Optic Exterior Slack Storage W/O Holes hidden and organized.Slack storage box is used for exterior slack storage applications using single fiber cable. There are two stackable storage spools that allow storage of multiple single fiber cable drops. Both of these spools are removable. In an instance where only one spool is sufficient, the spool can either be secured at a lower level or can be mounted at an elevation onto the risers off the back of the inside of the box as a spool on the upper level. This allows additional storage under the spool.


Fiber Inside Corner, Inside corner for the self adhesive single fiber molding.



Fiber Flat Elbow, Flat elbow for the self adhesive single fiber molding.


Fiber Outside Corner,Outside corners for the self adhesive single fiber molding.


Self Adhesive Single Fiber Molding

Cable drawing hooks are made of metal,hanging hardware, hard material,with splint type and C type for option.The conduit box,pipe joint box single gang or double gang are made of PC material,fire restardant.
