4 Core Fiber Optic Termination Box Mini FTB Fiber ODF Outdoor feeder cable box Drop cable Box

4 Core Fiber Optic Termination Box Mini FTB Fiber ODF Outdoor feeder cable box Drop cable Box

    • 4 Core Fiber Optic Termination Box Mini FTB Fiber ODF Outdoor feeder cable box Drop cable Box
    • 4 Core Fiber Optic Termination Box Mini FTB Fiber ODF Outdoor feeder cable box Drop cable Box
    • 4 Core Fiber Optic Termination Box Mini FTB Fiber ODF Outdoor feeder cable box Drop cable Box
    • 4 Core Fiber Optic Termination Box Mini FTB Fiber ODF Outdoor feeder cable box Drop cable Box
    • 4 Core Fiber Optic Termination Box Mini FTB Fiber ODF Outdoor feeder cable box Drop cable Box
  • 4 Core Fiber Optic Termination Box Mini FTB Fiber ODF Outdoor feeder cable box Drop cable Box

    Product Details:

    Place of Origin: China
    Brand Name: YUHUI
    Certification: ISO,RHOS,UL,CE
    Model Number: YH-1068-4

    Payment & Shipping Terms:

    Minimum Order Quantity: 200pieces
    Price: Negotiation
    Packaging Details: 10piece/box
    Delivery Time: 20days
    Payment Terms: TT,LC,West Union
    Supply Ability: 10000pieces/month
    Contact Now
    Detailed Product Description
    Material: New ABS Material For The Box Body IP: IP65
    Mini Type: 210mm*140mm*40mm Capacity: 4/6cores
    Color: Gray Type: Outdoor/Indoor

    4 Core Mini FTB Outdoor Fiber Optic Terminal box with lock IP65 Plastic FTTH Box



    Quick Detail:



    1. ABS material used ensures the body strong and light.

    2. Protection Level: IP65.

    3. Water-proof design for outdoor uses, lock provided for extra security.resistance and dustproof,flame-retardant.

    4. Space saving! Double-layer design for easier installation and maintenances

    5. Dimensions: 210mm*140mm*40mm

    6. Adapter Capacity 4/6 SC/FC simplex adapters or LC duplex adapters

    7. Installation: Wall mounting or Pole mounting.



    Description:



     Plastic FTTH Fiber Optic Termination Box 4cores,a newly developed box for application of FTTH,outdoor or indoor application. The box is with smaller size and light and compact, especially suitable for protective connection of fiber cables and pigtails in FTTH.IP class: IP65

    Specification:

    Function:Cable termination,passive splitter

    Splitter installation:Splitter fixing bracket

    Adaptor type:SC simplex,LC duplex

    Maximal capacity: 4 fibers indoor fiber cables

    Cable inlet and outlet:1port to 4port

    Lock function: lock with a plastic key,and two plastic sliplock, easy to operation.

    Diemention:210mm*140mm*40mm (Two type capacity for this size:4cores and 6cores)

    Installation: Wall mounting or Pole mounting.

    Complied with Rohs



    The FTTH Installation Accessories Set concludes,junction box,fiber wall socket (also named Single family unit rosette,SFU rosette),draw hooks,cable clamp,cable wall bushings,cable glands,cable clips,tail duct,cable wiring duct,nail clip,IPC,Tension Clamp,Suspension Clamp,Anchor clamp,PG Clamp and aerial cable fittings,plastic dead end clamp,dead end clamp,metal tension clamp,plastic tension clamp.



    Cable bushings were originally designed for indoor use on sheet rock.Cable bushings are plastic grommets inserted into a wall to provide a clean appearance for coax cable,fiber optic cable and all cable entry. Cable bushings are a low cost and fast alternative to installing traditional wall plates.They protect the cable from sharp edges when in applications. We offer different shape and size cable wall bushings,wall tubes,fiber inside corner,fiber outside corner,flat elbow,raceway duct fitting,raceway molding,bend radius,tail duct,cable clamp,wiring duct.All used for fiber optic cabling and other wire cabling projects.



    Fiber Optic Exterior Slack Storage W/O Holes hidden and organized.Slack storage box is used for exterior slack storage applications using single fiber cable. There are two stackable storage spools that allow storage of multiple single fiber cable drops. Both of these spools are removable. In an instance where only one spool is sufficient, the spool can either be secured at a lower level or can be mounted at an elevation onto the risers off the back of the inside of the box as a spool on the upper level. This allows additional storage under the spool.



    Applications:

    • FTTx, FTTH, FTTB, FTTO, Telecom network, CATV.Provide fusion and storage appliance for optical cables,for indoor fiber optic cable distribution.

    Specifications :



    Material Cold rolled steel for the box, ABS for the tray
    Operating Temperature -40°C~+60°C
    Relative Humidity <95%(+40°C)
    Insulated resistance ≥2x10MΩ/500V(DC)
    Capacity 4/6core (12core,24core,48core,72core,96core,144core is available)
    Installation Method (in overstriking ) Floor Standing / wall mounted / pole mounted / rack mounted / corridor mounted / mounted in cabinet
