    Product Details:

    Place of Origin: China
    Brand Name: YUHUI
    Certification: ISO,RHOS,UL,CE
    Model Number: YH-2009

    Payment & Shipping Terms:

    Minimum Order Quantity: 50pieces
    Price: Negotiation
    Packaging Details: 1piece/box
    Delivery Time: 20days
    Payment Terms: TT,LC,West Union
    Supply Ability: 5000pieces/month
    Contact Now
    Detailed Product Description





    Telecom Network Frame Network Serve Cabinet Open Rack With Adjusted Fixing Panel



    Quick Detail:



    1. Material:Cold rolled steel with powder coat finishing

    2. 19 inch standard floor open network server racks45U.

    3. With fixing panels

    4. Screw type

    5. With feet

    6. Size: 600*600*2000mm

    7. Packing:Whole pack or in Bulk



    Description:



    Features:
    1. Front door and side door easy to install and maintain.
    2. Cable entry on the top cover and bottom panel with adjustable sizes.
    3. Popular front door with toughened glass.
    4. Painting color:black and grey on your requirement .

    Technical Parameters:
    1. Main material: Cold rolled steel.
    2. Surface finish:Degreasing, pickling, phosphoric, powder coated.
    3. Degree of protection:IP20.

    Accessories:
    Power Panel ;Fixed Shell;Cabinet Fans.



    This cost-effective range of server cabinets is available in a combination of 600mm or 800mm widths with a 600mm,800mm or 1000mm depth. All cabinets are available in 18U to 45U heights with either a glass or mesh front door.



    Complied with Standards:

    ANSI/EIA RS-310-DIEC297-2DIN41494;PART1DIN41494;PART7, ETSI standard.



    Thickness:

    Mounting Rail: 1.5mm,Frame of front door: 1.5mm,Mounting Rail:1.5mm,

    Others:1.0 or1.2mm


    Standard Accessory :

    A.screw and nut. B.with 4pcs castor and adjusters. C.with 2 fixed shelf. D.with 2 fans for 600*600 type, 4fans for 600*800 and 600*1000type. E.1 piece PDU



     Lockable and reversible quick-release front and rear doors

     Perforated steel rear door

     Two lockable quick-release lift-out steel side panels

     Fully adjustable front & rear profiles with U height markings

     Removable roof panel for flood wiring or cooling

     Adjustable size bottom cable access aperture

     Manufactured from SPCC cold rolled steel

     With Ventilated door which is better for abstraction of heat .



    Applications:



    Data and telecom network, LAN and file server workstation or computer control center system.





    Specifications :





    Item No. YH-2009
    Main material Cold rolled steel
    Capacity/U 18/20/25/30/35/42U,as customer required
    Color Grey/Black
    Width/mm 600/800
    Depth/mm 600/800/1000
    Thickness Mounting Rail: 1.5mm,Frame of front door: 1.5mm,Mounting Rail: 1.5mm,Others:1.0 or1.2mm
    Degree of Protection IP20
